Detroit Hoist Top Running Double Girder Crane (Low Profile), 5.5 Ton Capacity, 26 FPM Lift Speed, 80 FPM Trolley Speed, 104" Trolley Gauge, Model DB11LH77-26
DB11LH77-26
Detroit Hoist Top Running Double Girder Crane (Low Profile), 5.5 Ton Capacity, 26 FPM Lift Speed, 80 FPM Trolley Speed, 104" Trolley Gauge, Model DB11LH77-26
DB11LH77-26

  • Guaranteed Fitment

    Always the correct part

  • In-House Experts

    We know our products

  • Added Value

    FREE in house engineering and design assistance

  • Wordwide Delivery

    Free shipping on all Harrington orders over 500LBS

Detroit Hoist Top Running Double Girder Crane (Low Profile), 5.5 Ton Capacity, 26 FPM Lift Speed, 80 FPM Trolley Speed, 104" Trolley Gauge, Model DB11LH77-26

Write a Review
$29,000.00
$25,375.00
(You save $3,625.00 )
SKU: DB11LH77-26
Weight: 2,600.00 LBS
Shipping: Calculated at Checkout
Capacity: 10,000 - 19,999 lbs
Lift: 77.2 ft
Mounting: Top Running
Configuration: Double Girder
Voltage: 230/3/60
Adding to cart… The item has been added
Detroit Hoist Top Running Double Girder Crane (Low Profile), 5.5 Ton Capacity, 26 FPM Lift Speed, 80 FPM Trolley Speed, 104" Trolley Gauge, Model DB11LH77-26

Detroit Hoist Top Running Double Girder Crane (Low Profile), 5.5 Ton Capacity, 26 FPM Lift Speed, 80 FPM Trolley Speed, 104" Trolley Gauge, Model DB11LH77-26

$29,000.00
$25,375.00
(You save $3,625.00 )

Detroit Hoist Top Running Double Girder Crane (Low Profile), 5.5 Ton Capacity, 26 FPM Lift Speed, 80 FPM Trolley Speed, 104" Trolley Gauge, Model DB11LH77-26

$29,000.00
$25,375.00
(You save $3,625.00 )
Description

The Top Running Double Girder Low Profile crane, model DB11LH77-26, is engineered for efficiency and reliability in heavy-duty lifting applications. With a robust capacity of 5.50 tons and an impressive hoist lift speed of 26.00 feet per minute, this crane is perfectly suited for tackling moderate loads in industrial environments where precision and safety are paramount.

Designed with a low-profile suspension/mount, this crane excels in facilities with limited overhead space, ensuring that it provides superior support while occupying minimal vertical clearance. Its two-part line reeving system allows for lifting heights of up to 77 feet and 3 inches, giving operators the flexibility they need for a variety of lifting tasks. The advanced closed-loop vector variable frequency drive (VFD) technology enhances control during lifting operations, contributing to increased productivity and safety.

  • Top running double girder low-profile design ensures robust support and stability.
  • 5.50-ton capacity ideal for moderate load handling.
  • Hoist lift speed of 26.00 feet per minute for quick vertical movements.
  • 7.5 KW hoist motor delivers reliable and powerful lifting performance.
  • Max trolley speed of 80.00 feet per minute for efficient horizontal load movement.
  • Two 0.55 kW trolley motors ensure smooth and reliable operation.
  • CMAA Class D classification for standard weather-resistant service.
  • Compatible with 230VAC, 3-phase, 60Hz electric power supply.
  • 104-inch trolley gauge for optimal spacing between runway beams.
  • Approximate weight of 2600 lbs for easy installation without compromising structural integrity.
  • Premium-grade graphite ductile iron wheels and sheaves designed for durability.
  • Dynamic braking with overload protection promotes safety during operation.
  • Optional hoist speed of 90 Hz available upon request for increased performance.

The Top Running Double Girder Low Profile crane is crafted with safety and efficiency in mind. Whether utilized for manufacturing, warehousing, or outdoor applications, this crane guarantees reliable operation under various conditions. Trust in the unmatched performance of the DB11LH77-26 for your material handling needs, and experience the difference in productivity and efficiency it brings to your operations.

Warranty Information
The Company warrants the equipment against defects in material and workmanship for one (1) year from the date of shipment, provided operation is maintained within Class D service conditions, and will replace free of charge, F.O.B. its manufacturing plant, any part (other than wire rope or rope guide rings) found defective, provided the purchaser immediately informs the Company of the defect and no repairs or alterations have been performed by the purchaser or a third party without the Company's written approval; this warranty excludes normal wear and parts inherently subject to premature wear, and the Company is not responsible for phase reversal on the connected power station network, nor liable for damages caused by improper installation or use, lifting loads above rated capacity, or consequential damages, claims, expenditures, or losses arising from operational delays or work stoppages caused by defective equipment. All repairs during the warranty period must be authorized by the Company, and the warranty applies only if the purchaser provides a signed Equipment Certification Form certifying that the equipment has been properly installed, tested, and is in satisfactory working order; the warranty excludes damage caused by improper storage, installation, unauthorized repairs, misuse, improper wiring or electrical service, improper handling, overloading, unsuitable fuels or oils, improper modifications or maintenance, faulty construction or foundations, unsuitable building grounds, chemical/electro-chemical/electrical influences, or other circumstances beyond the Company's fault, and all warranties become null and void if the purchaser or any subsequent user engages in such improper conduct or if such circumstances occur, in which case the Company is free of all obligations, costs, and liabilities under the warranty. All warranties extend only to the purchaser in privity of contract with the Company, and the purchaser - not the Company - is solely responsible for informing equipment users of all warranty and liability limitations; except as stated, no express, implied, or statutory warranty is made by the Company, and the Company is free of any warranty obligations should the purchaser default on agreed payment terms.
