Description

The Top Running Double Girder model DB16T50-18 from Detroit sets the standard in heavy lifting equipment with its impressive 8.25-ton capacity. Engineered for efficiency and reliability, this hoist is perfect for industries requiring robust performance for lifting substantial loads.

Designed to simplify the handling of heavy materials, this model incorporates advanced engineering to achieve a maximum hoist lift speed of 18.00 feet per minute and a trolley speed of 80.00 feet per minute. The sophisticated 3-part reeving system ensures that users can maneuver loads with precision while maximizing vertical reach of up to 50 feet and 8 inches. The Top Running Double Girder is truly an essential tool for any demanding operational environment.

  • Capacity: Lifting capacity of 8.25 tons, ideal for heavy loads.
  • Reeving/Lift: Features a 3-part reeving system with 50'­8" lift height.
  • Hoist Lift Speed: Maximum hoisting speed of 18.00 FPM for efficient operations.
  • Hoist Motor: Powerfully built with a 7.5 KW motor for reliable lifting.
  • Hoist Control: Closed-loop vector VFD control for accurate hoisting.
  • Trolley Speed: Maximum travel speed of 80.00 FPM for quick horizontal movement.
  • Trolley Motor: Dual 0.55 KW motors for smooth and effective propulsion.
  • Trolley Control: Sensorless vector VFD control ensures precise movement along tracks.
  • Power Supply: Operates on 230VAC, 3-phase, 60Hz (+/- 5%) standard voltage.
  • CMAA Class: Complies with CMAA standards, designed for indoor service in class D conditions.
  • Trolley Gauge: Stability ensured with a trolley gauge of 78.00 inches.
  • Premium Build: Features durable components such as graphite ductile iron wheels.
  • Control Features: UL508A listed control panel for reliable performance.
  • Safety Mechanisms: Built-in overload protection and dynamic braking for enhanced safety.
  • Customization: 110 VAC or optional 24 VDC control voltage; 90 Hz hoist speed for additional capability.

This Top Running Double Girder hoist isn’t just about raw power; it’s about delivering a safe, efficient, and user-friendly lifting experience. Ideal for construction sites, factories, and warehouses, it makes heavy lifting easier and safer, ensuring that your operation runs smoothly without interruption. Invest in the Top Running Double Girder, and elevate your productivity to new heights.

Warranty Information
The Company warrants the equipment against defects in material and workmanship for one (1) year from the date of shipment, provided operation is maintained within Class D service conditions, and will replace free of charge, F.O.B. its manufacturing plant, any part (other than wire rope or rope guide rings) found defective, provided the purchaser immediately informs the Company of the defect and no repairs or alterations have been performed by the purchaser or a third party without the Company's written approval; this warranty excludes normal wear and parts inherently subject to premature wear, and the Company is not responsible for phase reversal on the connected power station network, nor liable for damages caused by improper installation or use, lifting loads above rated capacity, or consequential damages, claims, expenditures, or losses arising from operational delays or work stoppages caused by defective equipment. All repairs during the warranty period must be authorized by the Company, and the warranty applies only if the purchaser provides a signed Equipment Certification Form certifying that the equipment has been properly installed, tested, and is in satisfactory working order; the warranty excludes damage caused by improper storage, installation, unauthorized repairs, misuse, improper wiring or electrical service, improper handling, overloading, unsuitable fuels or oils, improper modifications or maintenance, faulty construction or foundations, unsuitable building grounds, chemical/electro-chemical/electrical influences, or other circumstances beyond the Company's fault, and all warranties become null and void if the purchaser or any subsequent user engages in such improper conduct or if such circumstances occur, in which case the Company is free of all obligations, costs, and liabilities under the warranty. All warranties extend only to the purchaser in privity of contract with the Company, and the purchaser - not the Company - is solely responsible for informing equipment users of all warranty and liability limitations; except as stated, no express, implied, or statutory warranty is made by the Company, and the Company is free of any warranty obligations should the purchaser default on agreed payment terms.
