Detroit Hoist Top Running Double Girder Crane, 3.3 Ton Capacity, 26 FPM Lift Speed, 80 FPM Trolley Speed, 78" Trolley Gauge, Model DB7T77-26
DB7T77 -26
video
Detroit Hoist Top Running Double Girder Crane, 3.3 Ton Capacity, 26 FPM Lift Speed, 80 FPM Trolley Speed, 78" Trolley Gauge, Model DB7T77-26
DB7T77 -26

  • Guaranteed Fitment

    Always the correct part

  • In-House Experts

    We know our products

  • Added Value

    FREE in house engineering and design assistance

  • Wordwide Delivery

    Free shipping on all Harrington orders over 500LBS

Detroit Hoist Top Running Double Girder Crane, 3.3 Ton Capacity, 26 FPM Lift Speed, 80 FPM Trolley Speed, 78" Trolley Gauge, Model DB7T77-26

Write a Review
$24,000.00
$21,000.00
(You save $3,000.00 )
SKU: DB7T77-26
Weight: 2,400.00 LBS
Shipping: Calculated at Checkout
Capacity: 5,000 - 9,999 lbs
Lift: 77.2 ft
Mounting: Top Running
Configuration: Double Girder
Voltage: 230/3/60
Adding to cart… The item has been added
Detroit Hoist Top Running Double Girder Crane, 3.3 Ton Capacity, 26 FPM Lift Speed, 80 FPM Trolley Speed, 78" Trolley Gauge, Model DB7T77-26

Detroit Hoist Top Running Double Girder Crane, 3.3 Ton Capacity, 26 FPM Lift Speed, 80 FPM Trolley Speed, 78" Trolley Gauge, Model DB7T77-26

$24,000.00
$21,000.00
(You save $3,000.00 )

Detroit Hoist Top Running Double Girder Crane, 3.3 Ton Capacity, 26 FPM Lift Speed, 80 FPM Trolley Speed, 78" Trolley Gauge, Model DB7T77-26

$24,000.00
$21,000.00
(You save $3,000.00 )
Description

Designed for heavy-duty lifting, the Top Running Double Girder model DB7T77-26, with a capacity of 3.30 tons, delivers unparalleled performance and reliability in industrial settings. This powerhouse crane is engineered to ensure efficiency and safety, making it the perfect choice for any demanding job.

When it comes to lifting capability, this hoist stands out with a maximum lift height of 77 feet and 3 inches, allowing users to reach impressive elevations with ease. Its hoist operates at a speed of 26 feet per minute, showcasing remarkable efficiency for extensive operations. Coupled with a trolley speed reaching up to 80 feet per minute, this crane is sure to streamline your workflow and enhance productivity.

  • Top Running Double Girder construction for enhanced stability and heavy load handling.
  • Capable of lifting 3.30 tons, ensuring it supports substantial loads.
  • Maximum lift height of 77 feet and 3 inches for versatile applications.
  • Hoist lift speed of 26 feet per minute for quick operational capability.
  • Equipped with a powerful 7.5 kW motor for robust performance.
  • Closed-loop vector VFD control for responsive and precise hoist handling.
  • Trolley speed reaches up to 80 feet per minute, increasing operational efficiency.
  • Two 0.55 kW trolley motors providing smooth and reliable movement.
  • Sensorless vector VFD control ensuring exact trolley positioning.
  • Electric powered with standard voltage of 230VAC, 3-phase, 60Hz for compatibility.
  • Built to CMAA Class D standards, ensuring reliability in diverse atmospheres and locations.
  • Generous 78 inch trolley gauge for effective maneuvering across beams.
  • Weight of approximately 2400 lbs, allowing for stable ground support.

This crane is meticulously engineered with features such as 4-pole AC squirrel cage motors that deliver both hoist and trolley movements with precision. The system includes dynamic braking capabilities for safety and accurate positioning without fatigue. Premium-grade graphite ductile iron wheels ensure durability for extended use, while the industrial control panel is UL508A c UL us listed, designed for resilience in various weather conditions. With adjustable electronic encoder limits and motor overload protection, the Top Running Double Girder crane guarantees superior performance in challenging environments.

Warranty Information
The Company warrants the equipment against defects in material and workmanship for one (1) year from the date of shipment, provided operation is maintained within Class D service conditions, and will replace free of charge, F.O.B. its manufacturing plant, any part (other than wire rope or rope guide rings) found defective, provided the purchaser immediately informs the Company of the defect and no repairs or alterations have been performed by the purchaser or a third party without the Company's written approval; this warranty excludes normal wear and parts inherently subject to premature wear, and the Company is not responsible for phase reversal on the connected power station network, nor liable for damages caused by improper installation or use, lifting loads above rated capacity, or consequential damages, claims, expenditures, or losses arising from operational delays or work stoppages caused by defective equipment. All repairs during the warranty period must be authorized by the Company, and the warranty applies only if the purchaser provides a signed Equipment Certification Form certifying that the equipment has been properly installed, tested, and is in satisfactory working order; the warranty excludes damage caused by improper storage, installation, unauthorized repairs, misuse, improper wiring or electrical service, improper handling, overloading, unsuitable fuels or oils, improper modifications or maintenance, faulty construction or foundations, unsuitable building grounds, chemical/electro-chemical/electrical influences, or other circumstances beyond the Company's fault, and all warranties become null and void if the purchaser or any subsequent user engages in such improper conduct or if such circumstances occur, in which case the Company is free of all obligations, costs, and liabilities under the warranty. All warranties extend only to the purchaser in privity of contract with the Company, and the purchaser - not the Company - is solely responsible for informing equipment users of all warranty and liability limitations; except as stated, no express, implied, or statutory warranty is made by the Company, and the Company is free of any warranty obligations should the purchaser default on agreed payment terms.
