Product Overview
Bishamon LV-10 – Compact Hydraulic Lift Table
Ergonomic Lifting. Compact Power. Built for Versatility.
The Bishamon LV-10 is a light-duty hydraulic lift table designed to enhance ergonomics and improve productivity in assembly, packaging, and workstation applications. With a 1,000 lb capacity, the LV-10 delivers reliable, manual hydraulic lifting power in a compact footprint—ideal for tight spaces and lighter material handling tasks.
This table helps reduce worker strain by allowing users to position loads at the ideal working height, minimizing bending and lifting. Its rugged steel frame, smooth foot-operated hydraulic system, and low-maintenance design makes it a dependable choice for light-duty lifting and positioning in industrial or commercial settings.
Key Features
- 1,000 lb Capacity – Perfect for handling small to medium-sized loads
- Manual Foot Pump – Smooth and controlled lifting without electricity or air
- Compact, Mobile Design – Easy to maneuver around tight workspaces
- Ergonomic Height Adjustment – Enhances worker comfort and efficiency
- Durable Steel Construction – Built to handle everyday industrial use
- Swivel Casters with Brakes – Provide mobility and locking stability
- Low Maintenance – Simple design for long-lasting performance with minimal upkeep
- Powder-Coated Finish – Resistant to wear, rust, and corrosion
Benefits
- Improves Ergonomics – Reduces bending, reaching, and lifting-related injuries
- Increases Efficiency – Speeds up assembly, inspection, and packaging tasks
- Ideal for Tight Spaces – Fits into compact work areas and under conveyor lines
- No Power Needed – Operates entirely on a foot pump system—great for mobile or remote use
Technical Specifications – Bishamon LV-10
SpecificationDetails
Model LV-10
Capacity 1,000 lbs (454 kg)
Platform Size 20" x 32" (custom options available)
Lowered Height 10 inches
Raised Height 32 inches
Lift Mechanism Manual hydraulic (foot pump)
Lift Time Varies by user input
Mobility 4 swivel casters (2 with brakes)
Finish Powder-coated blue
Construction Heavy-duty welded steel
Weight Approx. 300 lbs
Applications Workstations, repair benches, packaging stations, light-duty material handling
