Product Overview
Bishamon LV-50WE – Wide Platform Electric Hydraulic Lift Table
Wider Support. Powered Lifting. Built for Ergonomic Efficiency.
The Bishamon LV-50WE is the wide-deck electric hydraulic version of the mid-capacity LV Series lift tables. With a lift capacity of 1,100 lbs and a generous 24" x 48" platform, the LV-50WE is designed to raise, lower, and position oversized loads with maximum efficiency and minimal operator effort.
Ideal for environments where frequent lifting is required, the LV-50WE features a powerful electric-hydraulic lift system operated by a foot switch, allowing for smooth, hands-free control. This heavy-duty mobile lift table increases workplace safety, reduces strain, and enhances productivity across a wide range of industrial, manufacturing, and assembly applications.
Key Features
- Electric Hydraulic Operation – Raises and lowers at the push of a foot switch
- Wide Platform (24" x 48") – Accommodates larger or longer loads with ease
- 1,100 lb Capacity – Suitable for mid-range lifting tasks in industrial settings
- Ergonomic Foot Control – Frees hands for better workflow and safety
- Rugged Welded Steel Frame – Durable, industrial-grade construction
- Heavy-Duty Casters – Provide easy maneuverability and secure placement
- Quiet, Smooth Lifting – The hydraulic system operates cleanly and efficiently
- Powder-Coated Finish – Resists chips, wear, and corrosion for long life
Benefits
- Improves Operator Ergonomics – Brings work to a comfortable height
- Supports Larger Items – The wide platform offers better load stability
- Boosts Productivity – Fast, hands-free lifting cycle reduces downtime
- Fully Mobile – Ideal for workstations, assembly lines, or production areas
- No Manual Effort Needed – Greatly reduces fatigue during repetitive tasks
Technical Specifications – Bishamon LV-50WE
SpecificationDetails
Model LV-50WE
Capacity 1,100 lbs (499 kg)
Platform Size 24" x 48"
Lowered Height 13 inches
Raised Height 36.5 inches
Lift Mechanism Electric hydraulic
Power Requirement 115V AC (standard plug)
Control Foot-operated switch
Casters 4 swivel (2 with locking brakes)
Construction Welded steel frame
Finish Powder-coated blue
Weight Approx. 350 lbs
Applications Oversized load handling, workstation elevation, light-duty manufacturing
