Product Overview
Bishamon LV-100WE – Wide Platform Electric Hydraulic Lift Table
Maximized Surface. Heavy-Duty Power. Ergonomic Efficiency at Scale.
The Bishamon LV-100WE is the wide-deck, high-capacity electric hydraulic lift table in the LV Series, built for safe and efficient lifting of large, heavy loads. With a 2,200 lb capacity and an expanded 24" x 48" platform, the LV-100WE provides greater surface area and stability—perfect for handling oversized equipment, materials, or assembly components in industrial settings.
Engineered with a durable electric-hydraulic system, the LV-100WE delivers fast, consistent lifting at the push of a foot switch. The wide platform is supported by a robust welded steel frame and smooth-rolling casters, making this unit ideal for repetitive lifting tasks in production lines, warehouses, MRO shops, and more.
Key Features
- High-Capacity (2,200 lbs) – Designed for tough industrial loads
- Wide Platform (24" x 48") – Ideal for bulky items and oversized pallets
- Electric Hydraulic Operation – Smooth lifting powered by standard 115V plug
- Ergonomic Foot Control – Hands-free operation improves workflow and safety
- Welded Steel Construction – Rigid, durable, and built for industrial longevity
- Locking Swivel Casters – For easy mobility and secure positioning
- Powder-Coated Finish – Long-lasting resistance to corrosion and wear
- Low Maintenance Design – Built to perform day in and day out with minimal upkeep
Benefits
- Enhances Ergonomics – Brings heavy or oversized materials to optimal working height
- Reduces Operator Fatigue – No manual pumping required
- Improves Material Handling Efficiency – Fast, safe, and precise positioning
- Versatile Use Cases – Perfect for assembly stations, packing lines, machine shops, and more
- Increased Surface Support – The wide platform offers improved stability for irregular loads
Technical Specifications – Bishamon LV-100WE
SpecificationDetails
Model LV-100WE
Capacity 2,200 lbs (998 kg)
Platform Size 24" x 48"
Lowered Height 13 inches
Raised Height 36.5 inches
Lift Mechanism Electric hydraulic
Power Requirement 115V AC (standard household outlet)
Control Foot-operated electrical switch
Casters 4 swivel (2 with locking brakes)
Construction Heavy-duty welded steel frame
Finish Durable blue powder-coated enamel
Weight Approx. 370 lbs
Applications Heavy-duty assembly, oversized parts staging, workstations, packaging lines
