Product Overview
Bishamon LV-100W – Wide Platform, Heavy-Duty Manual Lift Table
Maximum Strength. Expanded Capacity. Ergonomic Lifting for Oversized Loads.
The Bishamon LV-100W is the wide-deck version of the high-capacity LV Series lift tables, designed to lift and position up to 2,200 lbs of heavy, oversized materials safely and ergonomically. With its larger 24" x 48" platform, this manually operated hydraulic lift table provides greater surface support, making it ideal for applications involving large parts, bins, or heavy tools.
Engineered with industrial-grade steel, a durable hydraulic pump, and a smooth foot-operated lifting system, the LV-100W delivers consistent performance in demanding environments such as production floors, repair shops, and material handling work cells. Its robust mobility, enhanced platform size, and all-manual operation make it a reliable choice where both power and space efficiency are critical.
Key Features
- High Capacity (2,200 lbs) – Built for industrial-grade lifting tasks
- Wider Platform (24" x 48") – Accommodates larger or irregularly shaped loads
- Manual Hydraulic Lift – Operates via foot pedal—no electricity required
- Industrial Steel Frame – Durable welded construction for heavy-duty use
- Ergonomic Height Adjustment – Reduces bending and reaching injuries
- Swivel Casters with Brakes – Provide excellent mobility and stable positioning
- Low-Maintenance Design – Built for long-term, trouble-free operation
- Powder-Coated Finish – Protects against chips, rust, and industrial wear
Benefits
- Ergonomic Material Handling – Keeps loads at optimal working height
- Versatile Wide Deck – Great for bulky items, assemblies, or workstations
- No External Power Needed – Fully manual, ideal for mobile or remote use
- Maximized Durability – Designed to perform in harsh environments
- Easy to Operate and Maintain – Requires very minimal training and upkeep
Technical Specifications – Bishamon LV-100W
SpecificationDetails
Model LV-100W
Capacity 2,200 lbs (998 kg)
Platform Size 24" x 48"
Lowered Height 13 inches
Raised Height 36.5 inches
Lift Mechanism Manual hydraulic (foot pump)
Lift Speed Operator-controlled (foot pedal)
Casters 4 swivel (2 with locking brakes)
Construction Welded steel frame
Finish Blue powder-coated enamel
Weight Approx. 350 lbs
Applications Oversized load handling, heavy equipment staging, repair bays, assembly stations
