Bishamon L2K-TT4444 Turntable Lift Table

2,000 lb Capacity | 44" x 44" Rotating Platform | Ergonomic Work Positioner

The Bishamon L2K-TT4444 combines the reliable lifting performance of the Bishamon Lift2K™ Series with a heavy-duty 44" x 44" rotating turntable top, offering a complete ergonomic lifting and positioning solution. Designed for work environments that require frequent pallet rotation or access from multiple angles, this model minimizes worker strain and boosts productivity.

With a 2,000 lb lifting capacity and smooth hydraulic scissor action, the L2K-TT4444 lifts loads efficiently to an optimal working height and allows 360-degree rotation, reducing the need for bending, twisting, or overreaching. Ideal for packing stations, manufacturing lines, or shipping and receiving docks.

Key Features

• Integrated Turntable Platform – 44" x 44" square rotating top for full pallet access
• 2,000 lb Load Capacity – Ideal for most industrial and warehouse applications
• Ergonomic Work Positioning – Minimizes strain by bringing loads to a comfortable height and rotating them with ease
• Powered Electric Hydraulic Operation – Efficient lifting at the push of a button
• Durable Steel Construction – Built to withstand harsh industrial environments
• Compact Lowered Height – Just 8.38 inches, allowing for easy loading
• Smooth & Quiet Performance – Precision lifting with minimal noise
• ANSI MH29.1-2012 Compliant – Meets national safety standards

Technical Specifications

SpecificationDetails

Model L2K-TT4444

Series Lift2K™ with Turntable

Load Capacity 2,000 lbs

Platform Dimensions 44" x 44" Turntable Top

Vertical Travel 34 inches

Height (Lowered/Raised) 8.38" / 42.38"

Power Source 115 VAC

Lift Time (Up/Down) ~27 sec up / ~15 sec down

Rotation 360° Manual Turntable

Construction Heavy-duty welded steel

Compliance ANSI MH29.1-2012

Origin Made in USA

Best For

• Pallet building and wrapping
• Assembly stations requiring full access
• Production lines
• Shipping/receiving workstations
• Any application needing rotation and elevation
