Atlas Lifting & Rigging Compact Manual Chain Hoist 1/4 Ton Capacity – 10 Ft. Lift

Product Overview

Atlas Lifting & Rigging ACHC-0025-10 Compact Manual Chain Hoist

1/4 Ton Capacity – 10 Ft. Lift

The Atlas ACHC-0025-10 is a compact manual chain hoist designed for lightweight lifting applications where space, portability, and precision are key. With a 1/4 ton (500 lb) load capacity and a 10-foot standard lift, this hoist combines durability and efficiency in a small, easy-to-handle form factor.

Built with a rugged steel body and a hardened alloy load chain, this hoist offers smooth operation, dependable load control, and a reduced profile, making it useful for confined or elevated work areas. This hoist is perfectly suited for maintenance work, light fabrication, utility installations, and other tasks requiring secure, low-capacity lifting.

Key Features:

• Rated Capacity: 1/4 Ton (500 lbs)
• Compact & Lightweight Design: Optimized for portability and overhead use in tight spaces
• Durable Steel Housing: Built to withstand harsh working conditions while protecting internal gearing
• Hardened Alloy Load Chain: Grade 80 steel provides strength, wear resistance, and long service life
• Automatic Mechanical Brake: Reliable Weston-style load brake holds the load securely at any height
• Forged Swivel Hooks: Top and bottom hooks rotate 360° and include safety latches for secure anchoring
• Low Pull Force Requirement: Smooth gear operation reduces operator fatigue

Specifications:

SpecificationDetails

Model Number ACHC-0025-10

Rated Capacity 1/4 Ton (500 lbs)

Lift Height 10 Feet

Load Chain Material Grade 80 Alloy Steel

Load Chain Diameter 4 mm (approx.)

Effort to Lift Full Load ~25 lbs

Headroom (hook to hook) Approx. 9–10 inches

Hook Type Forged Steel, 360° Swivel, with Safety Latch

Brake Type Mechanical Weston-Style Load Brake

Net Weight Approx. 14–16 lbs

Compliance ASME B30.16, CE Certified
