Atlas Lifting & Rigging ACHC-0025-30

Compact 1/4 Ton Manual Chain Hoist – 30 Ft. Lift

The Atlas ACHC-0025-30 is a compact and highly portable manual chain hoist built for extended-lift, light-duty applications. With a 1/4 ton (500 lb) lifting capacity and an extended 30-foot lift height, this model is ideal for jobs requiring high vertical reach in confined or elevated areas. Its streamlined design, featuring swivel hooks and durable steel construction, makes it well-suited for utility work, facility maintenance, and overhead installations.

Despite its small size, the ACHC-0025-30 offers rugged reliability and smooth operation, ensuring consistent performance and long service life.

Features:

• Extended 30 Ft. Lift: Ideal for elevated lifting in compact or hard-to-reach spaces
• Compact & Lightweight: Easily transportable and simple to rig overhead
• All-Steel Housing: Protects internal components and resists jobsite wear
• Grade 80 Alloy Load Chain: Hardened for superior strength and resistance to deformation
• Weston-Style Mechanical Brake: Provides safe and secure load control
• 360° Forged Swivel Hooks: Equipped with safety latches for secure attachment
• Efficient Gear System: Reduces operator effort and enhances lifting precision

Technical Specifications:

SpecificationDetails

Model Number ACHC-0025-30

Rated Capacity 1/4 Ton (500 lbs)

Lift Height 30 Feet

Load Chain Material Grade 80 Alloy Steel

Load Chain Diameter 4 mm (approx.)

Effort to Lift Full Load ~25 lbs

Headroom (hook to hook) Approx. 9–10 inches

Hook Type Forged Steel, Swivel, w/ Safety Latch

Brake Type Mechanical Weston-Style Load Brake

Net Weight Approx. 24–26 lbs

Compliance ASME B30.16, CE Certified
