Atlas Lifting & Rigging ACHC-0025-20

Compact 1/4 Ton Manual Chain Hoist – 20 Ft. Lift

The Atlas ACHC-0025-20 is a compact manual chain hoist engineered for precise, lightweight lifting where extended reach and portability are essential. With a 1/4 ton (500 lb) lifting capacity and a 20-foot lift height, this hoist is ideal for field service, overhead utility work, and facility maintenance requiring vertical access and dependable control.

Its rugged steel body, premium Grade 80 load chain, and reliable braking system ensure safe operation, long service life, and smooth performance—all within a compact frame optimized for confined or elevated environments.

Features:

• Compact Design: Slim profile and light weight allow for overhead or tight-space use
• Heavy-Duty Steel Housing: Protects internal mechanisms and withstands harsh jobsite conditions
• Grade 80 Alloy Load Chain: Heat-treated for strength, wear resistance, and extended service
• Reliable Mechanical Brake: Weston-style braking system holds loads securely at any height
• 360° Swivel Hooks: Forged steel with safety latches for flexible, secure rigging
• Low Pull Effort: Smooth gear system reduces operator fatigue

Technical Specifications:

SpecificationDetails

Model Number ACHC-0025-20

Rated Capacity 1/4 Ton (500 lbs)

Lift Height 20 Feet

Load Chain Material Grade 80 Alloy Steel

Load Chain Diameter 4 mm (approx.)

Effort to Lift Full Load ~25 lbs

Headroom (hook to hook) Approx. 9–10 inches

Hook Type Forged Steel, Swivel, with Safety Latch

Brake Type Mechanical Weston-Style Load Brake

Net Weight Approx. 20–22 lbs

Standards Compliance ASME B30.16, CE Certified
