Spanco 301 Series Wall-Mounted Tie-Rod Supported Jib Crane - 2 Ton - 16 ft Span

Write a Review
$5,712.00
$4,641.00
(You save $1,071.00 )
SKU: 301-200-16
Weight: 663.00 LBS
Shipping: Calculated at Checkout
Hoist:: Hoist not included must be purchased separately
Capacity: 2,500 - 4,999 lbs
Type / Mounting: Wall Bracket
Span / Boom Length: 16' 0"
Adding to cart… The item has been added
Spanco 301 Series Wall-Mounted Tie-Rod Supported Jib Crane - 2 Ton - 16 ft Span

Spanco 301 Series Wall-Mounted Tie-Rod Supported Jib Crane - 2 Ton - 16 ft Span

$5,712.00
$4,641.00
(You save $1,071.00 )

The JIB Wall Tie Rod Supported 1 Ton Crane is engineered to meet the rigorous demands of indoor lifting applications, providing exceptional stability and durability. With a remarkable capacity of 4000 lbs and a generous span of 16 feet, this crane offers the perfect solution for warehouses, workshops, and manufacturing facilities seeking efficient material handling capabilities.

Designed for maximum performance, the crane features a clear span of 14 feet and 8 inches, ensuring ample room for maneuvering materials. Its robust wall tie rod system reinforces stability, allowing for safe operation even under heavy loads. The strategic placement of support bracket centers at 5 feet and 6 inches adds further reliability to the overall structure, making this crane a dependable choice for various indoor applications.

  • Capacity: Supports loads up to 4000 lbs
  • Span: Extends up to 16 feet
  • Clear Span: Provides a working space of 14 feet and 8 inches
  • Thrust/Pull Force: Capable of exerting a thrust or pull force of 15870 lbs
  • Beam Size: S10x25.4# for added strength
  • Support Bracket Centers: Positioned at 2 feet and 3 inches apart
  • Tie Rod Length: Conveniently measures 13 feet and 4 inches
  • Flange Width: Robust 4.66 inches for stability
  • Coating: Finished with a protective yellow spray paint for enhanced visibility and aesthetics
  • Hoist: Please note, hoist must be purchased separately

Engineered with precision, the JIB Wall Tie Rod Supported 1 Ton Crane ensures operational excellence while prioritizing safety and durability. This crane is perfect for lifting and transporting heavy materials in an indoor environment, allowing for seamless workflow optimization. Invest in the JIB 301-200-16 crane, and experience the ideal blend of functionality and strength, tailored to your specific lifting needs.

PtP Spanco, Inc. warrants its products to be free from defects in material and workmanship as follows: manual systems and equipment for ten years, and motorized systems and equipment along with paint and finishes for non-aluminum components for two years. Specifically, manual workstation bridge crane, jib crane, and gantry crane products are warranted against defects in material and workmanship for ten years or 20,000 hours from the date of shipment to the first retail purchaser, covering only nonwearable parts except that wearable wheels on manually operated workstation end trucks and hoist trolleys are also included; motorized equipment is warranted for two years or 4,000 hours from the date of shipment, and paint and finishes are warranted for two years, with coating-related claims requiring documentation of the product's application and environmental conditions from delivery through the time of claim. All warranty claims must be approved by PtP Spanco, Inc. before any work is performed, and its obligation is limited to repairing or replacing products at the factory or an approved location, with no other express, implied, or statutory warranties honored - including any warranty of merchantability or fitness for a particular purpose - and PtP Spanco, Inc. reserves the right to reject claims due to harsh or inappropriate environmental conditions. PtP Spanco, Inc. is not liable for indirect, incidental, or consequential damages (including lost profits, operating costs, loss of production, or travel expenses); components or accessories it did not manufacture; defective equipment or system failure caused by misuse, negligence, or improper installation or maintenance; equipment used beyond its rated capacity or service factors; unauthorized rework or modification; freight charges and damage caused by freight carriers; or loss, injury, or property damage resulting from failure or defective operation. Under the reimbursement disclaimer, written notice of any claimed system defect must be given within ninety (90) days of shipment, all reimbursement requests must include proper documentation, reimbursement is provided as a credit unless otherwise approved by PtP Spanco, Inc. management, labor reimbursement is capped at $90 per hour, and all reimbursement remains subject to PtP Spanco, Inc. management approval.
