NERP Electric Chain Hoist with Push Trolley 10' Lift-Capacity 5 Tons, NERP050L Electric Chain Hoist with Push Trolley HARRINGTON

Product Overview

Upgrade your workshop with the NERP050L-10 HARRINGTON NERP Electric Chain Hoist with Push Trolley 10' Lift. This versatile and cost-effective solution is designed to effortlessly transport heavy loads, making your lifting and lowering tasks a breeze. The powerful motor ensures smooth and efficient operation, while the convenient push button control offers easy maneuverability and precise control over the height adjustment.The NERP050L-10 HARRINGTON NERP Electric Chain Hoist with Push Trolley is built to withstand the toughest working conditions. It is designed to provide reliable performance and exceptional durability, allowing you to tackle even the most demanding lifting tasks with confidence. Whether you need to lift 5 Tons, this hoist has the capacity to handle your needs.With its push trolley system, this electric chain hoist allows for smooth movement along beams and tracks. This feature makes it ideal for various applications, such as in workshops, warehouses, construction sites, and more. The push trolley ensures easy and efficient load transportation, reducing the time and effort required for manual lifting and shifting.The NERP050L-10 HARRINGTON NERP Electric Chain Hoist with Push Trolley 10' Lift is designed with user convenience in mind. The lightweight and compact design makes it easy to carry and install, allowing you to quickly set up and start using it. The hoist is also equipped with safety features to ensure the protection of both the operator and the load being lifted.Experience the ease and reliability of the NERP050L-10 HARRINGTON NERP Electric Chain Hoist with Push Trolley 10' Lift in your workshop today. Upgrade your lifting capabilities, improve productivity, and enhance safety with this exceptional hoist and trolley combination. Don't miss out on this opportunity to revolutionize your workflow. Get yours now and discover the difference it can make in your operations.

Product Specifications

.

Part Number:

NERP050L-10

Color:

Yellow

Hoist Lift:

10 ft

Product:

Electric Chain Hoist, 10,000 lb, 10 ft, Push Trolley=Hoist Mount=Push Trolley

Includes:

10 Year Brake Warranty, Chain Container, Push Trolley, Quick Disconnect Plugs On Pendant And Power Cords

Lift Speed:

11 fpm

Housing Width:

17 1/2 in

Manufacturers Warranty Length:

10 yr Brake Warranty, 3 yr

Housing Depth:

10 1/2 in

Housing Length:

28 7/8 in

For Minimum Beam Flange Width:

4 in

For Maximum Beam Flange Width:

7 1/32 in

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

17 1/2 in

Body Depth:

10 1/2 in

For Minimum Beam Height:

6 11/16 in

Body Length:

28 7/8 in

Minimum Radius Curve:

90 19/32 in

Maximum Lifting Length:

10 ft

Controller Cord Length:

6 ft

Trolley Wheel Diameter:

6 7/10 in

Lifting Hook Opening Width:

1 29/32 in

Minimum Retracted Length:

33 3/32 in

Load Capacity:

10,000 lb

Minimum Between Hooks:

35 3/8 in

Motor HP:

4.7 hp

Phase:

3

Standards:

ANSI/ASME B30.16, ASME HST-1M, NFPA 70, RoHS Compliant, UL 1340

Voltage:

208/230/460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

2

Thermal Protection:

Yes

Control Cord:

6 ft

Amps @ Low Volts:

16.4 A

Number of Speeds:

1

Trolley Configuration:

Push Trolley

Trolley Speed:

Not Applicable

Features:

Count Hour Meter, Extreme Duty Motor, Push Trolley, Smart Brake Technology

Material:

Die Cast Aluminum

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

DC Current

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

11 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Push Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

2

Motor Horsepower:

4 3/4 hp

Headroom:

35 5/16 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

10,000 lb

Current at Minimum Voltage:

16.4 A

Trolley Wheel Material:

Steel

Current at Maximum Voltage:

7.9 A

Body Finish:

Enamel

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
