Harrington NERP Series Electric Chain Hoist with Push Trolley - 10 Ton - 10 ft Lift

Write a Review
$21,551.87
$16,029.20
(You save $5,522.67 )
SKU: NERP100L-10-10
Condition: New
Weight: 747.00 LBS
Shipping: Free Shipping
Part Number: NERP100L-10
Color: Yellow
Hoist Lift: 10 ft
product: Electric Chain Hoist, 20,000 lb, 10 ft, Push Trolley, Hoist Mount: Push Trolley
Includes: 10 Year Brake Warranty, Chain Container, Push Trolley, Quick Disconnect Plugs On Pendant And Power Cords
Lift Speed: 5.5 fpm
Housing Width: 13 1/4 in
Manufacturers Warranty Length: 10 yr Brake Warranty, 3 yr
Housing Depth: 10 1/2 in
Housing Length: 28 7/8 in
For Minimum Beam Flange Width: 5 1/2 in
For Maximum Beam Flange Width: 8 21/32 in
For Maximum Beam Height: Not Applicable
MFR Warranty Length: 1 yr
Body Width: 13 1/4 in
Body Depth: 10 1/2 in
For Minimum Beam Height: 7 5/16 in
Body Length: 28 7/8 in
Minimum Radius Curve: 118 3/32 in
Maximum Lifting Length: 10 ft
Controller Cord Length: 6 ft
Trolley Wheel Diameter: 7 3/10 in
Lifting Hook Opening Width: 3 3/16 in
Minimum Retracted Length: 46 1/2 in
Load Capacity: 20,000 - 29,999 lbs
Minimum Between Hooks: 46 1/2 in
Motor HP: 4.75 hp
Phase: 3
Standards: ANSI/ASME B30.16, ASME HST-1M, NFPA 70, RoHS Compliant, UL 1340
Fits Brand: Harrington Hoists Inc
Lubrication: Oil Bath
Clutch: Friction Clutch
Reeving: 4
Thermal Protection: Yes
Control Cord: 6 ft
Amps @ Low Volts: 16.4 A
Number of Speeds: 1
Trolley Configuration: Push Trolley
Trolley Speed: Not Applicable
Features: Count Hour Meter, Extreme Duty Motor, Push Trolley, Smart Brake Technology
Lifting Hook Material: Carbon Steel
Includes Clutch: Clutch Included
Overload Protection Included: Yes
Brake Type: DC Current
Chain Grade: Grade 80
Maximum Lift Speed: Not Applicable
Included Components: Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook
Fixed Lift Speed: 5.5 fpm
Clutch Type: Friction Clutch
Minimum Lift Speed: Not Applicable
Pendant IP Rating: IP65
Chain Finish: Nickel Plated
Controls: Push Button Pendant, Mount Type: Push Trolley
Starts and Stops per Hour: 360
Duty Classification: H4
Maximum Pulling Capacity: Not Applicable
Number of Reeves: 4
Motor Horsepower: 4 3/4 hp
Headroom: 46 1/2 in
Includes Brake: Brake Included
For Outdoor Use: Yes
Hoist IP Rating: IP55
Lifting Hook Type: Swivel Hook with Safety Latch
Maximum Lifting Capacity: 20,000 lb
Current at Minimum Voltage: 16.4 A
Trolley Wheel Material: Steel
Current at Maximum Voltage: 7.9 A
Body Finish: Enamel
Number of Load Chains: 1
Body Material: Aluminum
Trolley IP Rating: Not Applicable
Programmable: Non-Programmable
Suspension / Mounting: Plain (Push) Trolley
Control: Single Speed
Capacity: 20,000 - 29,999 lbs
Lift: 10 ft
Voltage: 208/230-460-3-60
Adding to cart… The item has been added
Harrington NERP Series Electric Chain Hoist with Push Trolley - 10 Ton - 10 ft Lift

Harrington NERP Series Electric Chain Hoist with Push Trolley - 10 Ton - 10 ft Lift

$21,551.87
$16,029.20
(You save $5,522.67 )

Harrington NERP Series Electric Chain Hoist with Push Trolley - 10 Ton - 10 ft Lift

$21,551.87
$16,029.20
(You save $5,522.67 )
The NERP100L-10 HARRINGTON NERP Electric Chain Hoist with Push Trolley is the ultimate solution for your heavy load transportation needs. Whether you require it for your workshop or job site, this electric hoist with a 10-foot lift capacity is here to make your life easier.Gone are the days of manual lifting and struggling with subpar equipment. The NERP100L-10 HARRINGTON NERP Electric Chain Hoist with Push Trolley is designed for small workshops and infrequent moves. Its durable construction ensures its longevity, while its efficient operation guarantees seamless lifting tasks.This hoist is equipped with a convenient push trolley, making load transportation hassle-free. No more wasting time and energy on moving heavy items; simply attach them to the hoist and let it do the work for you. Boost your productivity and streamline your workflow with this high-quality and easy-to-operate hoist.The NERP100L-10 HARRINGTON NERP Electric Chain Hoist with Push Trolley comes in various weight Capacity ranging from 10 Tons. No matter the size or weight of your load, this hoist can handle it with ease. Say goodbye to the stress of handling heavy items and welcome the convenience and efficiency this hoist brings.Investing in the NERP100L-10 HARRINGTON NERP Electric Chain Hoist with Push Trolley will revolutionize your workshop or job site. With its superior performance and reliability, you can trust this hoist to get the job done. Don't miss out on the opportunity to effortlessly move heavy items and enhance your workflow. Order yours now and start experiencing the difference it makes in your operations.
All products sold by Harrington Hoists, Inc. (HHI) are warranted to be free from defects in material and workmanship from the date of shipment, with coverage periods varying by product type - 1 year for electric and air powered hoists (excluding (N)ER2 and EQ/SEQ hoists), powered trolleys, powered Tiger Track jibs and gantries, crane components, below-the-hook devices, and spare/replacement parts; 2 years for manual hoists and trolleys and beam clamps; 3 years for (N)ER2 hoists, EQ/SEQ hoists, (T)EM/(T)SEM hoists, and RY hoists; 5 years for manual Tiger Track jibs and gantries and hoist motor brakes for EQ/SEQ, (T)EM/(T)SEM, and RY; and 10 years for the (N)ER2 brake and TNER hoist motor brake - provided the buyer notifies HHI in writing within sixty (60) days of discovering any alleged defect and the product has been used according to manufacturer recommendations without abuse, lack of maintenance, misuse, negligence, or unauthorized repairs or alterations. If HHI's inspection confirms a defect in material or workmanship within the applicable warranty period, HHI will, at its discretion, repair or replace the part or product free of charge (not including installation), with delivery made F.O.B. HHI's place of business for U.S. customers or FCA HHI's U.S. location for international customers under Incoterms 2010; no warranty claim will be honored without valid proof of purchase, the customer must obtain a Return Goods Authorization before shipping the product freight-prepaid along with an explanation of the complaint, repaired products remain covered for the rest of the original warranty period, replacement parts installed after the original warranty period carry only a one-year replacement warranty (not including installation) from installation, and if no defect is found or the defect falls outside the warranty's scope, the customer is responsible for return shipping costs. HHI disclaims all other express or implied warranties, including merchantability or fitness for a particular purpose, and will not be liable for death, personal injury, property damage, or incidental, contingent, special, or consequential damages, losses, or expenses arising from the use or misuse of its products, regardless of whether such damage results from any act or failure to act by HHI, whether negligent, willful, or otherwise.
