NERP Electric Chain Hoist with Push Trolley 20' Lift-Capacity 1/8 Tons NERP001H Electric Chain Hoist with Push Trolley HARRINGTON

Product Overview

The NERP001H-20 HARRINGTON Electric Chain Hoist with Push Trolley redefines convenience and reliability in material handling. Specifically designed for workshops and industrial settings, this advanced hoist combines robust performance with user-friendly features, making it an essential tool for lifting heavy loads up to 1/8 tons.

Capable of lifting up to 20 feet, this hoist offers unprecedented vertical reach, allowing you to handle heavy machinery, tools, and other cumbersome objects without the strain of manual labor. Say goodbye to the hassle of coordinating multiple workers or struggling with awkward loads; the NERP001H-20 empowers you to lift and transport items efficiently and safely with minimal effort.

Featuring a push trolley for seamless mobility, the hoist glides smoothly along the beam, granting you the freedom to position it optimally for your specific needs. This versatility eliminates the need for costly cranes and complicated setups, providing a practical solution for both temporary and ongoing lifting tasks.

Safety is paramount in any lifting operation, and the NERP001H-20 does not compromise on this aspect. Constructed from high-quality materials, it is built to endure the rigors of heavy-duty applications. Equipped with essential safety features including overload protection and a dual braking system, you can work with confidence knowing your load is secure while in transit.

Investing in the NERP001H-20 Electric Chain Hoist with Push Trolley means investing in enhanced productivity and a safer workspace. Streamline your material handling processes and elevate your workshop capabilities with this powerful piece of equipment. Enjoy operational efficiency and peace of mind knowing that the HARRINGTON hoist is designed to meet your toughest lifting demands, ensuring a well-organized and effective working environment.

Product Specifications

.

Part Number:

NERP001H-20

Color:

Yellow

Hoist Lift:

20 ft

Product:

Electric Chain Hoist, 250 lb, 20 ft, Push Trolley=Hoist Mount=Push Trolley

Includes:

10 Year Brake Warranty, Chain Container, Push Trolley, Quick Disconnect Plugs On Pendant And Power Cords

Lift Speed:

55 fpm

Housing Width:

12 5/8 in

Manufacturers Warranty Length:

10 yr Brake Warranty, 3 yr

Housing Depth:

6 5/8 in

Housing Length:

18 13/16 in

For Minimum Beam Flange Width:

2 1/4 in

For Maximum Beam Flange Width:

4 in

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

12 5/8 in

Body Depth:

6 5/8 in

For Minimum Beam Height:

3 in

Body Length:

18 13/16 in

Minimum Radius Curve:

43 5/16 in

Maximum Lifting Length:

20 ft

Controller Cord Length:

16 ft

Trolley Wheel Diameter:

3 1/5 in

Lifting Hook Opening Width:

1 3/32 in

Minimum Retracted Length:

15 19/32 in

Load Capacity:

250 lb

Minimum Between Hooks:

15 5/8 in

Motor HP:

0.75 hp

Phase:

3

Standards:

ANSI/ASME B30.16, ASME HST-1M, NFPA 70, RoHS Compliant, UL 1340

Voltage:

208/230/460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

1

Thermal Protection:

Yes

Control Cord:

16 ft

Amps @ Low Volts:

3.4 A

Number of Speeds:

1

Trolley Configuration:

Push Trolley

Trolley Speed:

Not Applicable

Features:

Count Hour Meter, Extreme Duty Motor, Push Trolley, Smart Brake Technology

Material:

Die Cast Aluminum

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

DC Current

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

55 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Push Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

3/4 hp

Headroom:

15 19/32 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

250 lb

Current at Minimum Voltage:

3.4 A

Trolley Wheel Material:

Steel

Current at Maximum Voltage:

1.7 A

Body Finish:

Enamel

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
