Product Overview
The NERP001H Electric Chain Hoist with Push Trolley from HARRINGTON is an essential addition to any workshop, delivering efficiency and reliability in transporting heavy loads. With a lifting capacity of 1/8 tons, this robust hoist easily manages a variety of items, making it suitable for tasks ranging from small-scale projects to larger industrial operations.Featuring a generous 15-foot lift height, the NERP001H facilitates seamless movement of materials across different elevations in your workspace‚ perfect for loading and unloading trucks or relocating items to storage areas. The combination of the electric hoist and push trolley guarantees smooth operation, allowing for precise maneuvering of even the heaviest items.
Installation is straightforward, ensuring that the hoist can be mounted to the push trolley in no time. Users benefit from the convenience of easily moving heavy loads without the strenuous effort often associated with manual handling. The push trolley is engineered for a smooth, controlled motion, enhancing your efficiency and safety during operations.
Durability and reliability are hallmarks of the NERP001H-15, designed to withstand the demands of frequent use while delivering exceptional performance. This hoist and trolley combo is not just an investment in productivity; it‚ a commitment to quality that promises long-lasting service in your workshop.
Enhance your workspace with the NERP001H Electric Chain Hoist and Push Trolley. This versatile solution empowers you to tackle heavy lifting tasks effortlessly and effectively. Elevate your operational capabilities and experience the difference in performance. Choose the NERP001H-15 HARRINGTON for a powerful, efficient, and dependable lifting solution tailored for your needs.
Product Specifications
.Product Videos
Videos Hide Videos Show Videos
Custom Field
Part Number NERP001H-15
Color Yellow
Hoist Lift 15 ft
Product Electric Chain Hoist, 250 lb, 15 ft, Push Trolley=Hoist Mount=Push Trolley
Includes 10 Year Brake Warranty, Chain Container, Push Trolley, Quick Disconnect Plugs On Pendant And Power Cords
Lift Speed 55 fpm
Housing Width 12 5/8 in
Manufacturers Warranty Length 10 yr Brake Warranty, 3 yr
Housing Depth 6 5/8 in
Housing Length 18 13/16 in
For Minimum Beam Flange Width 2 1/4 in
For Maximum Beam Flange Width 4 in
For Maximum Beam Height Not Applicable
MFR Warranty Length 1 yr
Body Width 12 5/8 in
Body Depth 6 5/8 in
For Minimum Beam Height 3 in
Body Length 18 13/16 in
Minimum Radius Curve 43 5/16 in
Maximum Lifting Length 15 ft
Controller Cord Length 11 ft
Trolley Wheel Diameter 3 1/5 in
Lifting Hook Opening Width 1 3/32 in
Minimum Retracted Length 15 19/32 in
Load Capacity 250 lb
Minimum Between Hooks 15 5/8 in
Motor HP 0.75 hp
Phase 3
Standards ANSI/ASME B30.16, ASME HST-1M, NFPA 70, RoHS Compliant, UL 1340
Voltage 208/230/460V
Fits Brand Harrington Hoists Inc
Lubrication Oil Bath
Clutch Friction Clutch
Reeving 1
Thermal Protection Yes
Control Cord 11 ft
Amps @ Low Volts 3.4 A
Number of Speeds 1
Trolley Configuration Push Trolley
Trolley Speed Not Applicable
Features Count Hour Meter, Extreme Duty Motor, Push Trolley, Smart Brake Technology
Lifting Hook Material Carbon Steel
Includes Clutch Clutch Included
Overload Protection Included Yes
Brake Type DC Current
Chain Grade Grade 80
Maximum Lift Speed Not Applicable
Included Components Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook
Fixed Lift Speed 55 fpm
Clutch Type Friction Clutch
Minimum Lift Speed Not Applicable
Pendant IP Rating IP65
Chain Finish Nickel Plated
Controls Push Button Pendant=Mount Type=Push Trolley
Starts and Stops per Hour 360
Duty Classification H4
Maximum Pulling Capacity Not Applicable
Number of Reeves 1
Motor Horsepower 3/4 hp
Headroom 15 19/32 in
Includes Brake Brake Included
For Outdoor Use Yes
Hoist IP Rating IP55
Lifting Hook Type Swivel Hook with Safety Latch
Maximum Lifting Capacity 250 lb
Current at Minimum Voltage 3.4 A
Trolley Wheel Material Steel
Current at Maximum Voltage 1.7 A
Body Finish Enamel
Number of Load Chains 1
Body Material Aluminum
Trolley IP Rating Not Applicable
Programmable Non-Programmable
