NERP Electric Chain Hoist with Push Trolley 10' Lift-Capacity 1/8 Tons NERP001H Electric Chain Hoist with Push Trolley HARRINGTON

Product Overview

The NERP001H-10 HARRINGTON NERP Electric Chain Hoist with Push Trolley 10' Lift redefines load handling in small workshops and environments that require an efficient solution for occasional heavy lifting. This robust system offers a lifting capacity of 1/8 tons, making it an optimal choice for moving materials with ease and reliability.

Designed with the latest hoist technology, the NERP001H Electric Chain Hoist ensures dependable and seamless operations, eliminating the challenges of manual load transport. Compact yet potent, it incorporates a push trolley that is securely attached to the hoist, facilitating effortless maneuverability when shifting loads within your workspace or over short distances.

The integrated PT push trolley enhances stability, allowing users to transport heavy materials confidently and efficiently. From lifting components during assembly to repositioning equipment, this hoist-and-trolley combination streamlines tedious tasks, elevating productivity levels in any workshop setting.

Crafted from high-quality materials and precision-engineered for strength and durability, the NERP001H-10 can withstand the day-to-day demands of a busy work environment. Its reliable performance and solid build ensure you can depend on it for years of service, minimizing downtime and maintenance concerns.

Small workshop owners and professionals alike will find the NERP001H-10 an invaluable addition to their tool lineup, enhancing workflow and facilitating effortless movement of heavy loads. Investing in this electric chain hoist with push trolley not only simplifies lifting tasks but also fosters a more organized and effective workspace. Experience the unmatched efficiency of the NERP001H-10 HARRINGTON NERP Electric Chain Hoist and take your operations to the next level.

Product Specifications

.

Part Number:

NERP001H-10

Color:

Yellow

Hoist Lift:

10 ft

Product:

Electric Chain Hoist, 250 lb, 10 ft, Push Trolley=Hoist Mount=Push Trolley

Includes:

10 Year Brake Warranty, Chain Container, Push Trolley, Quick Disconnect Plugs On Pendant And Power Cords

Lift Speed:

55 fpm

Housing Width:

12 5/8 in

Manufacturers Warranty Length:

10 yr Brake Warranty, 3 yr

Housing Depth:

6 5/8 in

Housing Length:

18 13/16 in

For Minimum Beam Flange Width:

2 1/4 in

For Maximum Beam Flange Width:

4 in

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

12 5/8 in

Body Depth:

6 5/8 in

For Minimum Beam Height:

3 in

Body Length:

18 13/16 in

Minimum Radius Curve:

43 5/16 in

Maximum Lifting Length:

10 ft

Controller Cord Length:

6 ft

Trolley Wheel Diameter:

3 1/5 in

Lifting Hook Opening Width:

1 3/32 in

Minimum Retracted Length:

15 19/32 in

Load Capacity:

250 lb

Minimum Between Hooks:

15 5/8 in

Motor HP:

0.75 hp

Phase:

3

Standards:

ANSI/ASME B30.16, ASME HST-1M, NFPA 70, RoHS Compliant, UL 1340

Voltage:

208/230/460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Clutch:

Friction Clutch

Reeving:

1

Thermal Protection:

Yes

Control Cord:

6 ft

Amps @ Low Volts:

3.4 A

Number of Speeds:

1

Trolley Configuration:

Push Trolley

Trolley Speed:

Not Applicable

Features:

Count Hour Meter, Extreme Duty Motor, Push Trolley, Smart Brake Technology

Material:

Die Cast Aluminum

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

DC Current

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

55 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Push Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

3/4 hp

Headroom:

15 19/32 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

250 lb

Current at Minimum Voltage:

3.4 A

Trolley Wheel Material:

Steel

Current at Maximum Voltage:

1.7 A

Body Finish:

Enamel

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
