SNERP Electric Chain Hoist with Push Trolley 20' Lift-Capacity 3 Tons SNERP030C Electric Chain Hoist with Push Trolley HARRINGTON

Product Overview

The SNERP030C-20 HARRINGTON SNERP Electric Chain Hoist with Push Trolley is the ultimate lifting solution for extreme duty applications. With its powerful single-phase motor, this hoist is designed to handle heavy lifting tasks with ease, making it perfect for professional and industrial settings.Offering a capacity ranging from 3 tons and a 20-foot lift, the SNERP030C-20 provides exceptional strength and versatility. Whether you need to lift heavy machinery, equipment, or materials, this electric hoist is built to handle your toughest jobs. With its incredible power, you can effortlessly lift and transport heavy objects, saving you time and effort.The SNERP030C-20 features a user-friendly design that ensures smooth operation and easy maneuverability. It comes with a push trolley that provides added convenience and flexibility. Whether you need to move your load horizontally or vertically, this hoist makes it easy to navigate through tight spaces and awkward angles.Durability is a key feature of this electric hoist. It is constructed with high-quality materials and components that can withstand even the harshest working conditions. You can rely on this hoist for years to come, making it a cost-effective investment for your business.Upgrade your lifting capabilities with the SNERP030C-20 HARRINGTON SNERP Electric Chain Hoist with Push Trolley and experience the convenience of reliable and efficient performance. Whether you're working in a warehouse, construction site, or industrial setting, this hoist is the ultimate tool for heavy lifting. Trust in the power and efficiency of the SNERP030C-20 to get the job done safely and effectively.

Product Specifications

.

Part Number:

SNERP030C-20

Color:

Yellow

Hoist Lift:

20 ft

Product:

Electric Chain Hoist, 6,000 lb, 20 ft, Push Trolley=Hoist Mount=Push Trolley

Includes:

Chain Container,, Push Trolley

Lift Speed:

3.5 fpm

Housing Width:

16 1/2 in

Manufacturers Warranty Length:

1 yr

Housing Depth:

8 5/16 in

Housing Length:

26 7/8 in

For Minimum Beam Flange Width:

3 1/4 in

For Maximum Beam Flange Width:

6 1/32 in

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

16 1/2 in

Body Depth:

8 5/16 in

For Minimum Beam Height:

6 in

Body Length:

26 7/8 in

Minimum Radius Curve:

66 29/32 in

Maximum Lifting Length:

20 ft

Controller Cord Length:

16 ft

Trolley Wheel Diameter:

5 4/5 in

Lifting Hook Opening Width:

1 11/16 in

Minimum Retracted Length:

29 5/16 in

Load Capacity:

6,000 lb

Minimum Between Hooks:

28 7/8 in

Motor HP:

1.2 hp

Phase:

1

Standards:

ANSI/ASME B30.16, ASME HST-1M

Voltage:

115/230V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

2

Thermal Protection:

Option

Control Cord:

16 ft

Amps @ Low Volts:

23.9 A

Number of Speeds:

1

Trolley Configuration:

Push Trolley

Trolley Speed:

Not Applicable

Features:

Extreme-Duty, Fan-Cooled Motor, Heavy Cast-Iron Chain Guide, Friction Clutch, Oil Bath-Lubricated, Heat-Treated Gearing, Self-Adjusting Maintenance-Free Brake

Material:

Die Cast Aluminum

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

Pull Rotor

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

3.5 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Push Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

2

Motor Horsepower:

1 1/4 hp

Headroom:

28 13/16 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

6,000 lb

Current at Minimum Voltage:

23.9 A

Trolley Wheel Material:

Steel

Current at Maximum Voltage:

0

Body Finish:

Enamel

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
