SNERP Electric Chain Hoist with Push Trolley 20' Lift-Capacity 1 Tons SNERP010L Electric Chain Hoist with Push Trolley HARRINGTON

Product Overview

The SNERP010L-20 HARRINGTON SNERP Electric Chain Hoist with Push Trolley 20'Lift is a powerhouse designed for extreme duty applications. Engineered with theneeds of heavy lifting in mind, this electric chain hoist delivers exceptionalperformance with its reliable single-phase power. With Capacity ranging from 1 Tons, this hoist is built to handle even the heaviest of loads withease.The push trolley feature ensures smooth movement along the track, providingmaximum control and efficiency. Whether you're in the manufacturing industry,construction, or any other sector that requires heavy lifting solutions, thisSNERP010L hoist is your ultimate partner.Experience the precision, durability, and efficiency of Harrington's SNERPelectric chain hoist and elevate your operations to new heights. This hoist isdesigned to withstand the toughest conditions and deliver top-notch performanceeach time. Its single-phase power ensures reliable operation, eliminating anydowntime or interruptions in your workflow.With a lift height of 20 feet, this hoist allows you to raise and lower heavyobjects with ease and precision. The push trolley feature ensures smooth andeffortless movement along the track, reducing strain on the operator andincreasing productivity.Whether you need to lift heavy machinery, equipment, or materials, theSNERP010L-20 HARRINGTON SNERP Electric Chain Hoist with Push Trolley is theperfect solution for your needs. It is built to handle the toughest jobs andcan be relied upon to deliver exceptional performance every time.Invest in the SNERP010L electric chain hoist with push trolley and experiencethe difference it can make in your operations. With its superior engineeringand durable construction, this hoist is designed to last for years, providingyou with a reliable and efficient lifting solution. Upgrade your equipment andtake your operations to the next level with the SNERP010L-20 HARRINGTON SNERPElectric Chain Hoist with Push Trolley.

Product Specifications

.

Part Number:

SNERP010L-20

Color:

Yellow

Hoist Lift:

20 ft

Product:

Electric Chain Hoist, 2,000 lb, 20 ft, Push Trolley=Hoist Mount=Push Trolley

Includes:

Chain Container,, Push Trolley

Lift Speed:

7 fpm

Housing Width:

13 13/16 in

Manufacturers Warranty Length:

1 yr

Housing Depth:

7 1/2 in

Housing Length:

23 1/4 in

For Minimum Beam Flange Width:

2 1/4 in

For Maximum Beam Flange Width:

5 in

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

13 13/16 in

Body Depth:

7 1/2 in

For Minimum Beam Height:

4 3/16 in

Body Length:

23 1/4 in

Minimum Radius Curve:

51 3/16 in

Maximum Lifting Length:

20 ft

Controller Cord Length:

16 ft

Trolley Wheel Diameter:

4 1/5 in

Lifting Hook Opening Width:

1 3/16 in

Minimum Retracted Length:

18 3/32 in

Load Capacity:

2,000 lb

Minimum Between Hooks:

16 1/2 in

Motor HP:

0.6 hp

Phase:

1

Standards:

ANSI/ASME B30.16, ASME HST-1M

Voltage:

115/230V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Item:

Electric Chain Hoist

Reeving:

1

Thermal Protection:

Option

Control Cord:

16 ft

Amps @ Low Volts:

16.9 A

Number of Speeds:

1

Trolley Configuration:

Push Trolley

Trolley Speed:

Not Applicable

Features:

Extreme-Duty, Fan-Cooled Motor, Heavy Cast-Iron Chain Guide, Friction Clutch, Oil Bath-Lubricated, Heat-Treated Gearing, Self-Adjusting Maintenance-Free Brake

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

Pull Rotor

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

7 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Push Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

5/8 hp

Headroom:

16 1/2 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

2,000 lb

Current at Minimum Voltage:

16.9 A

Trolley Wheel Material:

Steel

Current at Maximum Voltage:

8.5 A

Body Finish:

Enamel

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
