SNERP Electric Chain Hoist with Push Trolley 10' Lift-Capacity 1 Tons SNERP010L Electric Chain Hoist with Push Trolley HARRINGTON

Product Overview

The SNERP010L-10 HARRINGTON SNERP Electric Chain Hoist with Push Trolley 10' Lift-Capacity 1 Tons is the industry-leading solution for heavy lifting in demanding applications. Designed to provide unmatched power and reliability, this electric chain hoist ensures optimal performance even in extreme duty environments.With its single-phase power capability, the SNERP010L-10 delivers consistent and efficient lifting power. No matter the load, this hoist is built to handle it with ease. Featuring a 10' lift capacity and load Capacity ranging from 1/4 to 3 tons, it provides exceptional strength and flexibility for a wide range of lifting tasks.The standout feature of the SNERP010L-10 is its push trolley, which allows for effortless movement and positioning. This trolley system significantly increases productivity and efficiency, enabling you to lift and transport heavy loads with ease.Whether you're in the construction, manufacturing, or any other industry that requires heavy lifting, the SNERP010L-10 is the perfect choice. Its durable and high-quality construction ensures it can withstand the toughest conditions, providing you with a reliable and long-lasting solution for all your lifting needs.Safety is a top priority with the SNERP010L-10. It is designed with essential safety features such as overload protection and a load limit switch, ensuring secure and worry-free lifting operations. Lift with confidence and peace of mind knowing that this hoist is designed to prioritize your safety.Investing in the SNERP010L-10 HARRINGTON SNERP Electric Chain Hoist with Push Trolley means experiencing the ultimate power, reliability, and efficiency for all your heavy lifting tasks. Get the job done efficiently and safely with this exceptional electric chain hoist. Trust in its superior performance and enjoy the peace of mind that comes with using a top-of-the-line lifting solution.

Product Specifications

.

Part Number:

SNERP010L-10

Color:

Yellow

Hoist Lift:

10 ft

Product:

Electric Chain Hoist, 2,000 lb, 10 ft, Push Trolley=Hoist Mount=Push Trolley

Includes:

Chain Container,, Push Trolley

Lift Speed:

7 fpm

Housing Width:

13 13/16 in

Manufacturers Warranty Length:

1 yr

Housing Depth:

7 1/2 in

Housing Length:

23 1/4 in

For Minimum Beam Flange Width:

2 1/4 in

For Maximum Beam Flange Width:

5 in

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

13 13/16 in

Body Depth:

7 1/2 in

For Minimum Beam Height:

4 3/16 in

Body Length:

23 1/4 in

Minimum Radius Curve:

51 3/16 in

Maximum Lifting Length:

10 ft

Controller Cord Length:

6 ft

Trolley Wheel Diameter:

4 1/5 in

Lifting Hook Opening Width:

1 3/16 in

Minimum Retracted Length:

18 3/32 in

Load Capacity:

2,000 lb

Minimum Between Hooks:

16 1/2 in

Motor HP:

0.6 hp

Phase:

1

Standards:

ANSI/ASME B30.16, ASME HST-1M

Voltage:

115/230V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

1

Thermal Protection:

Option

Control Cord:

6 ft

Amps @ Low Volts:

16.9 A

Number of Speeds:

1

Trolley Configuration:

Push Trolley

Trolley Speed:

Not Applicable

Features:

Extreme-Duty, Fan-Cooled Motor, Heavy Cast-Iron Chain Guide, Friction Clutch, Oil Bath-Lubricated, Heat-Treated Gearing, Self-Adjusting Maintenance-Free Brake

Material:

Die Cast Aluminum

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

Pull Rotor

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

7 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Push Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

5/8 hp

Headroom:

16 1/2 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

2,000 lb

Current at Minimum Voltage:

16.9 A

Trolley Wheel Material:

Steel

Current at Maximum Voltage:

8.5 A

Body Finish:

Enamel

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
