SNERP Electric Chain Hoist with Push Trolley 20' Lift-Capacity 1/2 Tons SNERP005S Electric Chain Hoist with Push Trolley HARRINGTON

Write a Review
$4,519.44
$3,899.96
(You save $619.48 )
SKU: SNERP005S-20-20
Condition: New
Availability: In stock
Weight: 280.70 LBS
Shipping: Free Shipping
Part Number: SNERP005S-20
Color: Yellow
Hoist Lift: 20 ft
Product: Electric Chain Hoist, 1,000 lb, 20 ft, Push Trolley=Hoist Mount=Push Trolley
Includes: Chain Container,, Push Trolley
Lift Speed: 15 fpm
Housing Width: 13 13/16 in
Manufacturers Warranty Length: 1 yr
Housing Depth: 7 1/2 in
Housing Length: 23 1/4 in
For Minimum Beam Flange Width: 2 1/4 in
For Maximum Beam Flange Width: 5 in
For Maximum Beam Height: Not Applicable
MFR Warranty Length: 1 yr
Body Width: 13 13/16 in
Body Depth: 7 1/2 in
For Minimum Beam Height: 3 3/16 in
Body Length: 23 1/4 in
Minimum Radius Curve: 43 5/16 in
Maximum Lifting Length: 20 ft
Controller Cord Length: 16 ft
Trolley Wheel Diameter: 3 1/5 in
Lifting Hook Opening Width: 29/32 in
Minimum Retracted Length: 16 3/32 in
Load Capacity: 1,000 lb
Minimum Between Hooks: 15 3/8 in
Motor HP: 0.6 hp
Phase: 1
Standards: ANSI/ASME B30.16, ASME HST-1M
Voltage: 115/230V
Fits Brand: Harrington Hoists Inc
Lubrication: Oil Bath
Reeving: 1
Thermal Protection: Option
Control Cord: 16 ft
Amps @ Low Volts: 16.9 A
Number of Speeds: 1
Trolley Configuration: Push Trolley
Trolley Speed: Not Applicable
Features: Extreme-Duty, Fan-Cooled Motor, Heavy Cast-Iron Chain Guide, Friction Clutch, Oil Bath-Lubricated, Heat-Treated Gearing, Self-Adjusting Maintenance-Free Brake
Material: Die Cast Aluminum
Lifting Hook Material: Carbon Steel
Includes Clutch: Clutch Included
Overload Protection Included: Yes
Brake Type: Pull Rotor
Chain Grade: Grade 80
Maximum Lift Speed: Not Applicable
Included Components: Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook
Fixed Lift Speed: 15 fpm
Clutch Type: Friction Clutch
Minimum Lift Speed: Not Applicable
Pendant IP Rating: IP65
Chain Finish: Nickel Plated
Controls: Push Button Pendant=Mount Type=Push Trolley
Starts and Stops per Hour: 360
Duty Classification: H4
Maximum Pulling Capacity: Not Applicable
Number of Reeves: 1
Motor Horsepower: 5/8 hp
Headroom: 15 5/16 in
Includes Brake: Brake Included
For Outdoor Use: Yes
Hoist IP Rating: IP55
Lifting Hook Type: Swivel Hook with Safety Latch
Maximum Lifting Capacity: 1,000 lb
Current at Minimum Voltage: 16.9 A
Trolley Wheel Material: Steel
Current at Maximum Voltage: 8.5 A
Body Finish: Enamel
Number of Load Chains: 1
Body Material: Aluminum
Trolley IP Rating: Not Applicable
Programmable: Non-Programmable
Adding to cart… The item has been added
Description
The SNERP005S-20 HARRINGTON SNERP Electric Chain Hoist with Push Trolley is the ultimate solution for tackling heavy-duty applications. Its strength and reliability make it suitable for the toughest tasks, ensuring it can handle any challenge with ease.One of the standout features of this hoist is its ability to operate on single-phase power. This makes it incredibly versatile and allows you to use it in a wide range of settings without the need for a three-phase power source.With a lift capacity ranging from 1/2 Tons, the SNERP005S-20 can handle a variety of loads. Whether you need to lift smaller items or heavier equipment, this hoist has got you covered. Its sturdy construction ensures it can handle the weight without compromising performance.The included push trolley adds to the hoist's versatility, making movement smooth and seamless. Maneuvering the hoist and positioning it exactly where you need it becomes hassle-free. You have full control over your operations, enhancing efficiency and productivity.Durability and robust design are core features of the SNERP005S-20 HARRINGTON SNERP Electric Chain Hoist with Push Trolley. It is built to last, making it suitable for demanding environments where reliability is crucial. You can trust this hoist to consistently perform and deliver high-quality results.Upgrade your lifting capabilities with the SNERP005S-20 HARRINGTON SNERP Electric Chain Hoist with Push Trolley and experience the difference firsthand. Whether you work in construction, manufacturing, or any other field that requires heavy lifting, this hoist will enhance your productivity and efficiency. It offers unmatched strength, reliability, and performance.Get the job done right with the SNERP005S-20 HARRINGTON SNERP Electric Chain Hoist with Push Trolley. Invest in a product that is built to last and designed to handle the toughest tasks. Don't compromise when it comes to heavy-duty lifting ‚ choose the SNERP005S-20 HARRINGTON SNERP Electric Chain Hoist with Push Trolley and experience superior performance.
