Product Overview
The SNERP005L-20 HARRINGTON SNERP Electric Chain Hoist with Push Trolley 20' Lift-Capacity 1/2 Tons is a top-of-the-line hoist that delivers exceptional performance and reliability for all your heavy lifting needs. Designed to tackle extreme duty applications, this electric chain hoist is built to withstand the toughest conditions.With a sturdy and durable construction, this hoist can handle loads of up to 1/2 Tons, providing the power and strength needed to lift heavy objects effortlessly. It is the ideal choice for demanding work environments such as warehouses, construction sites, and manufacturing facilities.One of the standout features of the SNERP005L-20 Electric Chain Hoist is its single phase power capability. This means that it can operate efficiently with just one power source, making it convenient and cost-effective. You won't have to worry about complicated setups or multiple power connections.The push trolley system allows for smooth and effortless movement, making it easy to transport your loads from one location to another. This hoist provides the flexibility and ease of use needed for versatile work environments where mobility is essential.With Harrington's expertise in hoist manufacturing, you can trust that the SNERP005L-20 Electric Chain Hoist is a reliable and powerful solution. Harrington is known for producing high-quality hoists that meet the highest industry standards, and this electric chain hoist is no exception.Upgrade your lifting game with the SNERP005L-20 Electric Chain Hoist with Push Trolley SNERP005L today. Its exceptional capabilities, reliable performance, and user-friendly design make it the perfect solution for all your heavy lifting needs. Choose the SNERP005L-20 Electric Chain Hoist and experience the difference it can make in your work efficiency and productivity. Don't settle for anything less than the best.Product Specifications
.Product Videos
Videos Hide Videos Show Videos
Custom Field
Part Number SNERP005L-20
Color Yellow
Hoist Lift 20 ft
Product Electric Chain Hoist, 1,000 lb, 20 ft, Push Trolley=Hoist Mount=Push Trolley
Includes Chain Container,, Push Trolley
Lift Speed 7 fpm
Housing Width 13 in
Manufacturers Warranty Length 1 yr
Housing Depth 6 5/8 in
Housing Length 22 1/4 in
For Minimum Beam Flange Width 2 1/4 in
For Maximum Beam Flange Width 5 in
For Maximum Beam Height Not Applicable
MFR Warranty Length 1 yr
Body Width 13 in
Body Depth 6 5/8 in
For Minimum Beam Height 3 3/16 in
Body Length 22 1/4 in
Minimum Radius Curve 43 5/16 in
Maximum Lifting Length 20 ft
Controller Cord Length 16 ft
Trolley Wheel Diameter 3 1/5 in
Lifting Hook Opening Width 29/32 in
Minimum Retracted Length 15 13/32 in
Load Capacity 1,000 lb
Minimum Between Hooks 14 5/8 in
Motor HP 0.34 hp
Phase 1
Standards ANSI/ASME B30.16, ASME HST-1M
Voltage 115/230V
Fits Brand Harrington Hoists Inc
Lubrication Oil Bath
Reeving 1
Thermal Protection Option
Control Cord 16 ft
Amps @ Low Volts 7.7 A
Number of Speeds 1
Trolley Configuration Push Trolley
Trolley Speed Not Applicable
Features Extreme-Duty, Fan-Cooled Motor, Heavy Cast-Iron Chain Guide, Friction Clutch, Oil Bath-Lubricated, Heat-Treated Gearing, Self-Adjusting Maintenance-Free Brake
Material Die Cast Aluminum
Lifting Hook Material Carbon Steel
Includes Clutch Clutch Included
Overload Protection Included Yes
Brake Type Pull Rotor
Chain Grade Grade 80
Maximum Lift Speed Not Applicable
Included Components Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook
Fixed Lift Speed 7 fpm
Clutch Type Friction Clutch
Minimum Lift Speed Not Applicable
Pendant IP Rating IP65
Chain Finish Nickel Plated
Controls Push Button Pendant=Mount Type=Push Trolley
Starts and Stops per Hour 360
Duty Classification H4
Maximum Pulling Capacity Not Applicable
Number of Reeves 1
Motor Horsepower 3/8 hp
Headroom 14 19/32 in
Includes Brake Brake Included
For Outdoor Use Yes
Hoist IP Rating IP55
Lifting Hook Type Swivel Hook with Safety Latch
Maximum Lifting Capacity 1,000 lb
Current at Minimum Voltage 7.7 A
Trolley Wheel Material Steel
Current at Maximum Voltage 3.9 A
Body Finish Enamel
Number of Load Chains 1
Body Material Aluminum
Trolley IP Rating Not Applicable
Programmable Non-Programmable
