SNER Electric Chain Hoist 15' Lift-Capacity 1/4 Tons SNER003S Electric Chain Hoist HARRINGTON

Product Overview

The SNER003S-15 HARRINGTON SNER Electric Chain Hoist is a reliable and efficient solution for upgrading your lifting capabilities. With a capacity ranging from 1/4 Tons, this electric chain hoist is designed to handle a wide range of loads, making it suitable for industrial and commercial applications.The 15-foot lift height of this hoist provides versatility and flexibility in lifting tasks. Whether you need to lift objects to a specific height or require additional clearance, this hoist can meet your needs.Featuring a single-phase power source, the SNER003S-15 HARRINGTON SNER Electric Chain Hoist is incredibly convenient and easy to use. Simply plug it in, and you're ready to start lifting. It eliminates the need for complex setups or additional equipment.Reliability and performance are at the core of this hoist's design. Built to withstand tough lifting challenges, the SNER003S-15 HARRINGTON SNER Electric Chain Hoist is engineered for durability. It can handle continuous operations with ease, ensuring that your lifting tasks are completed efficiently and safely.Not only does this hoist offer impressive lifting capabilities, but it is also designed with user convenience in mind. Its compact and lightweight design makes it easy to maneuver and transport. Additionally, it comes with a range of safety features, such as a chain container to prevent accidents and a thermal motor protection device to prevent overheating.Upgrade your lifting capabilities with the SNER003S-15 HARRINGTON SNER Electric Chain Hoist. Whether you need to lift heavy loads in extreme applications or require a durable hoist for your industrial or commercial needs, this hoist is built to exceed your expectations. Trust Harrington, a trusted name in lifting solutions, to tackle all your lifting challenges.

Product Specifications

.

Part Number:

SNER003S-15

Color:

Yellow

Hoist Lift:

15 ft

Product:

Electric Chain Hoist, 500 lb, 15 ft, Hook Mounted-No Trolley, Yellow=Hoist Mount=Hook Mounted-No Trolley

Includes:

Chain Container

Lift Speed:

14 fpm

Housing Width:

9 15/16 in

Manufacturers Warranty Length:

1 yr

Housing Depth:

6 5/8 in

Housing Length:

22 3/16 in

For Minimum Beam Flange Width:

Not Applicable

For Maximum Beam Flange Width:

Not Applicable

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

9 15/16 in

Body Depth:

6 5/8 in

For Minimum Beam Height:

Not Applicable

Body Length:

22 3/16 in

Minimum Radius Curve:

Not Applicable

Maximum Lifting Length:

15 ft

Controller Cord Length:

11 ft

Trolley Wheel Diameter:

Not Applicable

Lifting Hook Opening Width:

29/32 in

Minimum Retracted Length:

13 13/16 in

Load Capacity:

500 lb

Minimum Between Hooks:

13 13/16 in

Motor HP:

0.34 hp

Phase:

1

Standards:

ASME B30.16, ASME HST-1, NFPA 70

Voltage:

115/230V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

1

Thermal Protection:

No

Control Cord:

11 ft

Amps @ Low Volts:

7.7 A

Number of Speeds:

1

Trolley Configuration:

Hook Mounted

Trolley Speed:

Not Applicable

Features:

Extreme-Duty, Fan-Cooled Motor, Heavy Cast-Iron Chain Guide, Friction Clutch, Oil Bath-Lubricated, Heat-Treated Gearing, Self-Adjusting Maintenance-Free Brake

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

Pull Rotor

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Safety Latch Hook

Fixed Lift Speed:

14 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Hook Mounted-No Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

3/8 hp

Headroom:

13 13/16 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

500 lb

Current at Minimum Voltage:

7.7 A

Trolley Wheel Material:

Not Applicable

Current at Maximum Voltage:

3.9 A

Body Finish:

Enamel

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
