SNER Electric Chain Hoist 10' Lift-Capacity 1/4 Tons SNER003S Electric Chain Hoist HARRINGTON

Product Overview

The SNER003S-10 HARRINGTON SNER Electric Chain Hoist is a reliable and powerful tool designed to meet your heavy-duty lifting needs. With a lift capacity of 1/4 Tons and a 10ft lift height, this electric chain hoist is perfect for extreme duty applications that require single-phase power.Manufactured by HARRINGTON, a trusted name in the industry, the SNER003S-10 is built to withstand the toughest tasks and deliver exceptional lifting capability. Its sturdy construction ensures durability and longevity, allowing you to depend on it for years to come.Ideal for a wide range of industries including manufacturing, construction, and logistics, this electric chain hoist provides the necessary power and reliability to handle all your heavy lifting requirements. Whether you need to move heavy materials or equipment, the SNER003S-10 will effortlessly get the job done, increasing your productivity and keeping your operations running smoothly.The SNER003S-10 is designed with efficiency in mind. Its efficient performance ensures that it operates smoothly and effectively, reducing the risk of accidents or damage. With its easy-to-use controls, you can effortlessly control the hoist, allowing for precise and controlled movements.Safety is paramount when it comes to lifting heavy loads, and the SNER003S-10 prioritizes it. Equipped with safety features such as overload protection, upper and lower limit switches, and a mechanical brake, this electric chain hoist ensures safe and secure lifting operations.Additionally, the SNER003S-10 is backed by HARRINGTON's commitment to quality and customer satisfaction. With their extensive industry experience and expertise, you can trust in the reliability and performance of this electric chain hoist.Experience the power and reliability of the SNER003S-10 HARRINGTON Electric Chain Hoist and take your heavy-duty lifting to the next level. Invest in this durable and efficient tool today and witness the difference it makes in your operations.

Product Specifications

.

Part Number:

SNER003S-10

Color:

Yellow

Hoist Lift:

10 ft

Product:

Electric Chain Hoist, 500 lb, 10 ft, Hook Mounted-No Trolley, Yellow=Hoist Mount=Hook Mounted-No Trolley

Includes:

Chain Container

Lift Speed:

14 fpm

Housing Width:

9 15/16 in

Manufacturers Warranty Length:

1 yr

Housing Depth:

6 5/8 in

Housing Length:

22 3/16 in

For Minimum Beam Flange Width:

Not Applicable

For Maximum Beam Flange Width:

Not Applicable

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

9 15/16 in

Body Depth:

6 5/8 in

For Minimum Beam Height:

Not Applicable

Body Length:

22 3/16 in

Minimum Radius Curve:

Not Applicable

Maximum Lifting Length:

10 ft

Controller Cord Length:

6 ft

Trolley Wheel Diameter:

Not Applicable

Lifting Hook Opening Width:

29/32 in

Minimum Retracted Length:

13 13/16 in

Load Capacity:

500 lb

Minimum Between Hooks:

13 13/16 in

Motor HP:

0.34 hp

Phase:

1

Standards:

ASME B30.16, ASME HST-1, NFPA 70

Voltage:

115/230V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

1

Thermal Protection:

No

Control:

6 ft

Control Cord:

6 ft

Amps @ Low Volts:

7.7 A

Number of Speeds:

1

Trolley Configuration:

Hook Mounted

Trolley Speed:

Not Applicable

Features:

Extreme-Duty, Fan-Cooled Motor, Heavy Cast-Iron Chain Guide, Friction Clutch, Oil Bath-Lubricated, Heat-Treated Gearing, Self-Adjusting Maintenance-Free Brake

Material:

Die Cast Aluminum

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

Pull Rotor

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Safety Latch Hook

Fixed Lift Speed:

14 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Hook Mounted-No Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

3/8 hp

Headroom:

13 13/16 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

500 lb

Current at Minimum Voltage:

7.7 A

Trolley Wheel Material:

Not Applicable

Current at Maximum Voltage:

3.9 A

Body Finish:

Enamel

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
