SEM Electric Hoist 20' Lift-Capacity 1000 Lbs SEM005C Electric Hoist HARRINGTON

Product Overview

The SEM005C-20 HARRINGTON SEM Electric Hoist is engineered to meet diverse lifting needs across multiple industries, including warehouses, manufacturing facilities, and construction sites. Designed specifically for single-phase power supply environments, it excels in compact spaces where efficiency is paramount.

Equipped with Solid State Relay (SSR) technology and a microcontroller unit (MCU), this electric hoist delivers impressive performance, ensuring a reliable and extended operational lifespan. With a robust lifting capacity of 1,000 lbs and a reach of 20 feet, the SEM005C-20 facilitates the smooth handling of heavy machinery, materials, and equipment, making it an indispensable tool for various industrial applications.

Safety is a top priority with the SEM005C-20. This hoist incorporates a suite of industry-leading safety features that prioritize both the well-being of operators and the protection of valuable assets. Its intuitive control system allows for straightforward operation, enabling users to lift and lower loads with confidence and ease.

The superior construction of the SEM005C-20 guarantees durability, making it well-suited to withstand even the most demanding work environments. Whether lifting items to elevated heights or managing substantial loads, this electric hoist delivers consistency and functionality, maximizing productivity in the workplace.

Investing in the SEM005C-20 HARRINGTON SEM Electric Hoist means choosing equipment that combines unparalleled reliability with robust performance. Upgrade your lifting operations and ensure a safe working environment by incorporating this high-quality hoisting solution into your daily operations. Trust in the SEM005C-20 to provide exceptional results, elevate your workflow, and bring peace of mind to your heavy lifting tasks.

Product Specifications

.

Part Number:

SEM005C-20

Color:

Yellow

Hoist Lift:

1

Product:

Electric Hoists=Hoist Mount=1

Includes:

Not Applicable

Lift Speed:

Not Applicable

For Minimum Beam Flange Width:

Not Applicable

For Maximum Beam Flange Width:

Not Applicable

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

5 yr

Body Width:

11 1/2 in

Body Depth:

9 13/32 in

For Minimum Beam Height:

Not Applicable

Body Length:

11 1/2 in

Minimum Radius Curve:

Not Applicable

Maximum Lifting Length:

20 ft

Controller Cord Length:

8 3/16 ft

Trolley Wheel Diameter:

Not Applicable

Lifting Hook Opening Width:

29/32 in

Minimum Retracted Length:

13 19/32 in

Phase:

1

Finish:

Nickel Plated

Number of Speeds:

1

Features:

LED Error Indicator, Protects the Hoist from Over winding, State-of-the-Art Control System using Solid State Relay (SSR) Technology and a Microcontroller Unit (MCU), Chain Guide Discharges the Chain from the Side of the Hoist Body preventing the Chai

Material:

Steel

Lifting Hook Material:

Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

Electromagnetic

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Rubber Bumpers

Fixed Lift Speed:

6 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Hook Mounted-No Trolley

Starts and Stops per Hour:

300

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

2

Motor Horsepower:

1/4 hp

Headroom:

13 19/32 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP65

Lifting Hook Type:

Hook with Safety Latch

Maximum Lifting Capacity:

1,000 lb

Current at Minimum Voltage:

4.6 A

Trolley Wheel Material:

Not Applicable

Current at Maximum Voltage:

2.3 A

Number of Load Chains:

1

Body Material:

Die-Cast Aluminum

Programmable:

Non-Programmable
