Harrington SEM Series Single-Phase Mini Hoist with Hook Suspension - 1000 lbs - 10 ft Lift

Write a Review
$3,433.67
$2,553.79
(You save $879.88 )
SKU: SEM005C-10
Condition: New
Availability: Subject to Availability
Weight: 35.30 LBS
Shipping: Calculated at Checkout
Part Number: SEM005C-10
Color: Yellow
Hoist Lift: 10 ft
product: Electric Hoists, Hoist Mount: 1
Includes: IP65
Lift Speed: 11 1/2 in
For Minimum Beam Flange Width: Not Applicable
For Maximum Beam Flange Width: Not Applicable
For Maximum Beam Height: Not Applicable
MFR Warranty Length: 5 yr
Body Width: 11 1/2 in
Body Depth: 9 13/32 in
For Minimum Beam Height: Not Applicable
Body Length: 11 1/2 in
Minimum Radius Curve: Not Applicable
Maximum Lifting Length: 10 ft
Controller Cord Length: 8 3/16 ft
Trolley Wheel Diameter: Not Applicable
Lifting Hook Opening Width: 29/32 in
Minimum Retracted Length: 13 19/32 in
Phase: 1
Number of Speeds: 1
Features: LED Error Indicator, Protects the Hoist from Over winding, State-of-the-Art Control System using Solid State Relay (SSR) Technology and a Microcontroller Unit (MCU), Chain Guide Discharges the Chain from the Side of the Hoist Body preventing the Chai
Lifting Hook Material: Steel
Includes Clutch: Clutch Included
Overload Protection Included: Yes
Brake Type: Electromagnetic
Chain Grade: Grade 80
Maximum Lift Speed: Not Applicable
Included Components: Chain Container, Pendant, Rubber Bumpers
Fixed Lift Speed: 6 fpm
Clutch Type: Friction Clutch
Minimum Lift Speed: Not Applicable
Pendant IP Rating: IP65
Chain Finish: Nickel Plated
Controls: Push Button Pendant, Mount Type: Hook Mounted-No Trolley
Starts and Stops per Hour: 300
Duty Classification: H4
Maximum Pulling Capacity: Not Applicable
Number of Reeves: 2
Motor Horsepower: 1/4 hp
Headroom: 13 19/32 in
Includes Brake: Brake Included
For Outdoor Use: Yes
Hoist IP Rating: IP65
Lifting Hook Type: Hook with Safety Latch
Maximum Lifting Capacity: 1,000 lb
Current at Minimum Voltage: 4.6 A
Trolley Wheel Material: Not Applicable
Current at Maximum Voltage: 2.3 A
Number of Load Chains: 1
Body Material: Die-Cast Aluminum
Programmable: Non-Programmable
Control: Single Speed
Capacity: 1,000 - 2,499 lbs
Lift: 10 ft
Voltage: 115/230-1-60
Adding to cart… The item has been added
Harrington SEM Series Single-Phase Mini Hoist with Hook Suspension - 1000 lbs - 10 ft Lift

Harrington SEM Series Single-Phase Mini Hoist with Hook Suspension - 1000 lbs - 10 ft Lift

$3,433.67
$2,553.79
(You save $879.88 )
The SEM005C-10 HARRINGTON SEM Electric Hoist is a game-changer for those looking to enhance productivity. Designed specifically for areas with single-phase power, this mini electric chain hoist delivers reliable and efficient operation.Featuring Solid State Relay (SSR) technology and a microcontroller unit (MCU), this electric hoist is built to last and perform at a high level. You can say goodbye to frequent breakdowns and say hello to seamless operation.Not only does the SEM005C-10 HARRINGTON SEM Electric Hoist excel in functionality, but it also impresses with its compactness. Ideal for industries with limited space for machinery, this hoist is a dream come true.With a lifting capacity 1000 lbs, this electric hoist is a powerhouse for handling heavy loads. It effortlessly lifts your materials and equipment, making even the most challenging projects a breeze.Equipped with a 10' lift, the SEM005C-10 HARRINGTON SEM Electric Hoist offers the flexibility to reach great heights with ease. No more struggling to elevate your materials; this hoist has you covered.Investing in this high-quality electric hoist not only elevates your projects but also streamlines your operations. Experience the efficiency and convenience of having a reliable, space-saving hoist at your disposal.Say goodbye to second-rate hoists that leave you stranded in the middle of a project. Upgrade to the SEM005C-10 HARRINGTON SEM Electric Hoist and revolutionize the way you work. Bid farewell to downtime and welcome increased productivity.Take your productivity to new heights with the SEM005C-10 HARRINGTON SEM Electric Hoist. Get yours today and watch your efficiency soar.
All products sold by Harrington Hoists, Inc. (HHI) are warranted to be free from defects in material and workmanship from the date of shipment, with coverage periods varying by product type - 1 year for electric and air powered hoists (excluding (N)ER2 and EQ/SEQ hoists), powered trolleys, powered Tiger Track jibs and gantries, crane components, below-the-hook devices, and spare/replacement parts; 2 years for manual hoists and trolleys and beam clamps; 3 years for (N)ER2 hoists, EQ/SEQ hoists, (T)EM/(T)SEM hoists, and RY hoists; 5 years for manual Tiger Track jibs and gantries and hoist motor brakes for EQ/SEQ, (T)EM/(T)SEM, and RY; and 10 years for the (N)ER2 brake and TNER hoist motor brake - provided the buyer notifies HHI in writing within sixty (60) days of discovering any alleged defect and the product has been used according to manufacturer recommendations without abuse, lack of maintenance, misuse, negligence, or unauthorized repairs or alterations. If HHI's inspection confirms a defect in material or workmanship within the applicable warranty period, HHI will, at its discretion, repair or replace the part or product free of charge (not including installation), with delivery made F.O.B. HHI's place of business for U.S. customers or FCA HHI's U.S. location for international customers under Incoterms 2010; no warranty claim will be honored without valid proof of purchase, the customer must obtain a Return Goods Authorization before shipping the product freight-prepaid along with an explanation of the complaint, repaired products remain covered for the rest of the original warranty period, replacement parts installed after the original warranty period carry only a one-year replacement warranty (not including installation) from installation, and if no defect is found or the defect falls outside the warranty's scope, the customer is responsible for return shipping costs. HHI disclaims all other express or implied warranties, including merchantability or fitness for a particular purpose, and will not be liable for death, personal injury, property damage, or incidental, contingent, special, or consequential damages, losses, or expenses arising from the use or misuse of its products, regardless of whether such damage results from any act or failure to act by HHI, whether negligent, willful, or otherwise.
