Top Running Double Girder, Capacity: 10.00 Ton, Hoist Lift Speed: 30.00 FPM Max, Trolley Speed: 80.00 FPM Max, Trolley Gauge: 108.0000", DRD20T112-30, Detroit

Type: Suspension / Mount Top Running Double Girder

Capacity: The Model DRD20T96-30 is engineered to handle heavy loads with a remarkable capacity of 10.00 tons. Its robust design and advanced features make it suitable for demanding industrial applications where precision and reliability are essential.

Reeving | Lift: With a 2-part reeving system, this crane offers an impressive lift height of 96 feet and 2 inches, providing extensive vertical reach for lifting tasks requiring significant elevation. This substantial lift height enhances versatility and adaptability for various lifting operations, ensuring efficient handling of diverse loads.

Hoist Lift Speed: Featuring a maximum hoist lift speed of 30.00 feet per minute (FPM), the Model DRD20T96-30 facilitates rapid and efficient vertical movement of loads. This high-speed capability ensures swift lifting and lowering operations, contributing to enhanced productivity and reduced cycle times.

Hoist Motor: Powered by a robust 15.5 kW hoist motor, this crane delivers exceptional performance and torque for lifting heavy loads with ease. The powerful motor ensures reliable and controlled movement, contributing to operational efficiency and safety during lifting operations.

Hoist Control: Equipped with closed-loop vector Variable Frequency Drive (VFD) control, the Model DRD20T96-30 offers precise and responsive hoisting operations. This advanced control system ensures accurate speed regulation, load handling, and positioning, optimizing performance and safety during lifting operations.

Trolley Speed: With a maximum trolley speed of 80.00 FPM, this crane enables rapid and precise horizontal movement of loads along the girder tracks. Whether transporting materials within a facility or positioning heavy components, the Model DRD20T96-30 ensures efficient handling and maneuverability.

Trolley Motor: Featuring two motors, each rated at 0.86 kW, the trolley system provides ample power for smooth and controlled movement across the working area. These motors deliver reliable propulsion, enabling precise positioning and efficient operation of the trolley.

Trolley Control: Utilizing sensorless vector VFD control, the trolley movement is accurately regulated, ensuring precise positioning and smooth operation. This advanced control system allows for responsive and efficient trolley movements, enhancing overall efficiency and safety during material handling tasks.

Power Supply: The Model DRD20T96-30 operates on electric power, with a voltage rating of 460VAC, 3-phase, and a frequency of 60Hz (+5% tolerance). This ensures compatibility with standard electrical systems, facilitating seamless integration into existing infrastructure.

CMAA Class | Atmosphere | Location Class: Compliant with CMAA standards and suitable for indoor service in atmosphere class D conditions, the Model DRD20T96-30 offers reliability and safety in various operating environments. Additionally, its weather-resistant design enhances durability and performance, allowing for operation in diverse weather conditions.

Trolley Gauge: With a trolley gauge measuring 96.0000 inches, the system ensures stability and proper alignment during horizontal movement along the girder tracks, enhancing safety and efficiency during material handling tasks.

Approximate Weight: Weighing approximately 3500.00 lbs, the Model DRD20T96-30 features a robust construction, ensuring durability and stability during lifting operations. Its sturdy build quality and reliable components contribute to its overall performance and longevity in demanding industrial environments.
