SNER Electric Chain Hoist 20' Lift-Capacity 1/4 Tons SNER003S Electric Chain Hoist HARRINGTON

Product Overview

The SNER003S-20 HARRINGTON SNER Electric Chain Hoist revolutionizes heavy lifting through its impressive design and advanced technology. Perfectly engineered for extreme duty applications, this hoist boasts unparalleled performance that meets the demands of various industries.

Powered entirely by single-phase electricity, the SNER003S-20 exemplifies convenience and efficiency. Forget about the hassle of complex power sources; simply plug it in, and you’re ready to go. This hoist has been crafted to effortlessly handle heavy lifting tasks, ensuring you achieve your objectives with minimal downtime.

• Lift Capacity: Capable of handling loads up to 1/4 tons, this hoist is perfect for a diverse range of applications, including the transportation of heavy machinery, construction materials, and other bulky items.
• Lift Height: With a remarkable lift height of 20 feet, the SNER003S-20 effortlessly reaches elevated areas, streamlining your productivity and allowing for efficient loading and unloading operations.
• Durability: Constructed to endure rugged conditions, this electric chain hoist is reliable and long-lasting, making it an ideal choice for warehouses, construction sites, and industrial facilities.
• Ease of Use: Simple plug-and-play operation eliminates the confusion of the multi-phase setups, enabling quick transitions between jobs.
• Safety Features: Built-in safety mechanisms ensure secure lifting, giving users peace of mind when operating heavy loads.

Transitioning to the SNER003S-20 HARRINGTON SNER Electric Chain Hoist means investing in an efficient, high-performing solution that significantly enhances your lifting operations. This hoist is designed to make manual lifting a thing of the past, replacing it with a seamless, high-performance experience. Upgrade your lifting capabilities today by incorporating this state-of-the-art hoist into your business and witness the substantial difference it can bring in terms of convenience, efficiency, and reliability.

Product Specifications

.

Part Number:

SNER003S-20

Color:

Yellow

Hoist Lift:

20 ft

Product:

Electric Chain Hoist, 500 lb, 20 ft, Hook Mounted-No Trolley, Yellow=Hoist Mount=Hook Mounted-No Trolley

Includes:

Chain Container

Lift Speed:

14 fpm

Housing Width:

9 15/16 in

Manufacturers Warranty Length:

1 yr

Housing Depth:

6 5/8 in

Housing Length:

22 3/16 in

For Minimum Beam Flange Width:

Not Applicable

For Maximum Beam Flange Width:

Not Applicable

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

9 15/16 in

Body Depth:

6 5/8 in

For Minimum Beam Height:

Not Applicable

Body Length:

22 3/16 in

Minimum Radius Curve:

Not Applicable

Maximum Lifting Length:

20 ft

Controller Cord Length:

16 ft

Trolley Wheel Diameter:

Not Applicable

Lifting Hook Opening Width:

29/32 in

Minimum Retracted Length:

13 13/16 in

Load Capacity:

500 lb

Minimum Between Hooks:

13 13/16 in

Motor HP:

0.34 hp

Phase:

1

Standards:

ASME B30.16, ASME HST-1, NFPA 70

Voltage:

115/230V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

1

Thermal Protection:

No

Classification:

H4

Control Cord:

16 ft

Amps @ Low Volts:

7.7 A

Number of Speeds:

1

Trolley Configuration:

Hook Mounted

Trolley Speed:

Not Applicable

Features:

Extreme-Duty, Fan-Cooled Motor, Heavy Cast-Iron Chain Guide, Friction Clutch, Oil Bath-Lubricated, Heat-Treated Gearing, Self-Adjusting Maintenance-Free Brake

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

Pull Rotor

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Safety Latch Hook

Fixed Lift Speed:

14 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Hook Mounted-No Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

3/8 hp

Headroom:

13 13/16 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

500 lb

Current at Minimum Voltage:

7.7 A

Trolley Wheel Material:

Not Applicable

Current at Maximum Voltage:

3.9 A

Body Finish:

Enamel

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
