Harrington EQ Series Electric Chain Hoist Dual Speed VFD - 1/8 Ton - 10 ft Lift

Write a Review
$2,777.74 - $3,033.22
SKU: EQ001SD-10
Condition: New
Availability: Subject to Availability
Weight: 71.00 LBS
Shipping: Calculated at Checkout
Part Number: EQ001SD
Color: Yellow
Hoist Lift: 10 ft
product: Electric Chain Hoist, 250 lb, Hook Mounted-No Trolley, Yellow Hoist Mount Hook Mounted-No Trolley
Includes: Chain Container
Lift Speed: 56/9.3 fpm
Housing Width: 14 13/32 in
Manufacturers Warranty Length: 3 yr
Housing Depth: 9 7/64 in
Housing Length: 17 19/64 in
For Minimum Beam Flange Width: Not Applicable
For Maximum Beam Flange Width: Not Applicable
For Maximum Beam Height: Not Applicable
MFR Warranty Length: 3 yr
Body Width: 14 13/32 in
Body Depth: 9 1/8 in
For Minimum Beam Height: 15 in
Body Length: 17 5/16 in
Minimum Radius Curve: 10 in
Maximum Lifting Length: 10 ft
Controller Cord Length: 6 ft
Trolley Wheel Diameter: Not Applicable
Lifting Hook Opening Width: 1 3/32 in
Minimum Retracted Length: 17 5/16 in
Load Capacity: 0 - 999 lbs
Minimum Between Hooks: 17 5/16 in
Motor HP: 0.625 hp
Phase: 3
Standards: ASME HST-4, C22.2 No.33/14-13/66, CSA, UL 508A
Fits Brand: Harrington Hoists Inc
Lubrication: Oil Bath
Reeving: 1
Thermal Protection: Yes
Control Cord: 6 ft
Amps @ Low Volts: 2.9 A
Number of Speeds: 2
Trolley Configuration: Hook/Suspension Bar Mounted
Trolley Speed: Not Applicable
Features: Extreme-Duty, Fan-Cooled Motor, No-Load High Speed, Self-Adjusting Maintenance-Free Brake, Unique Chain Guide, Variable Frequency Drive (VFD)
Lifting Hook Material: Carbon Steel
Includes Clutch: Clutch Included
Overload Protection Included: Yes
Brake Type: Pull Rotor
Chain Grade: Grade 80
Maximum Lift Speed: 56 fpm
Included Components: Chain Container, Pendant, Safety Latch Hook
Fixed Lift Speed: Not Applicable
Clutch Type: Friction
Minimum Lift Speed: 9.3 fpm
Pendant IP Rating: IP65
Chain Finish: Nickel Plated
Controls: Push Button Pendant, Mount Type: Hook Mounted-No Trolley
Starts and Stops per Hour: 120, 240
Duty Classification: H4
Maximum Pulling Capacity: Not Applicable
Number of Reeves: 1
Motor Horsepower: 5/8 hp
Headroom: 17 5/16 in
Includes Brake: Brake Included
For Outdoor Use: Yes
Hoist IP Rating: IP55
Lifting Hook Type: Swivel Hook with Safety Latch
Maximum Lifting Capacity: 250 lb
Current at Minimum Voltage: 5.1 A
Trolley Wheel Material: Not Applicable
Current at Maximum Voltage: 2.8 A
Body Finish: Epoxy Painted
Number of Load Chains: 1
Body Material: Aluminum
Trolley IP Rating: Not Applicable
Programmable: Programmable by Internal Controls
Suspension / Mounting: Hook
Control: Dual Speed
Capacity: 0 - 999 lbs
Lift: 10 ft
Voltage: 460/3/60
Adding to cart… The item has been added
Harrington EQ Series Electric Chain Hoist Dual Speed VFD - 1/8 Ton - 10 ft Lift

Harrington EQ Series Electric Chain Hoist Dual Speed VFD - 1/8 Ton - 10 ft Lift

$2,777.74 - $3,033.22

Harrington EQ Series Electric Chain Hoist Dual Speed VFD - 1/8 Ton - 10 ft Lift

$2,777.74 - $3,033.22

The EQ001SD-10 HARRINGTON EQ Electric Chain Hoist revolutionizes your industrial operations, providing exceptional lifting solutions that enhance workflow efficiency across various applications. This powerful hoist is engineered to manage medium to heavy-duty tasks with ease, boasting a reliable lift capacity of 1/8 ton.

Designed for both industrial environments and workstation applications, the EQ001SD-10 features a compact design for easy integration into tight spaces. Its robust construction ensures smooth operation, allowing you to tackle challenging lifting tasks while maintaining high efficiency and productivity levels. The hoist is equipped with advanced technological features that facilitate precise control over your lifting movements, enabling optimal performance in various settings.

  • Powerful Lift Capacity: Handles up to 1/8 ton with confidence, ideal for transporting machinery, tools, and materials.
  • 10-Foot Lift Height: Modifies your working range effectively, ensuring flexibility in maneuvering heavy loads.
  • Variable Frequency Drive: Promotes energy efficiency and offers exceptional control over lifting speed and movements.
  • Dual Speed Control: Provides versatility in operations with high and low-speed settings to suit different lifting requirements.
  • Compact Design: Facilitates installation in confined spaces without sacrificing strength or capability.
  • Durability: Built with high-quality materials to withstand demanding industrial applications.
  • Harrington Reliability: Trusted brand known for its commitment to quality and excellence in hoisting solutions.

The EQ001SD-10 HARRINGTON EQ Electric Chain Hoist stands out in its class, providing an optimal combination of power, precision, and portability. Elevate your occupational safety and productivity by implementing this hoist into your workspace. Make an intelligent investment in a trusted tool that not only meets but exceeds your lifting requirements, paving the way for a more efficient and effective operation.

All products sold by Harrington Hoists, Inc. (HHI) are warranted to be free from defects in material and workmanship from the date of shipment, with coverage periods varying by product type - 1 year for electric and air powered hoists (excluding (N)ER2 and EQ/SEQ hoists), powered trolleys, powered Tiger Track jibs and gantries, crane components, below-the-hook devices, and spare/replacement parts; 2 years for manual hoists and trolleys and beam clamps; 3 years for (N)ER2 hoists, EQ/SEQ hoists, (T)EM/(T)SEM hoists, and RY hoists; 5 years for manual Tiger Track jibs and gantries and hoist motor brakes for EQ/SEQ, (T)EM/(T)SEM, and RY; and 10 years for the (N)ER2 brake and TNER hoist motor brake - provided the buyer notifies HHI in writing within sixty (60) days of discovering any alleged defect and the product has been used according to manufacturer recommendations without abuse, lack of maintenance, misuse, negligence, or unauthorized repairs or alterations. If HHI's inspection confirms a defect in material or workmanship within the applicable warranty period, HHI will, at its discretion, repair or replace the part or product free of charge (not including installation), with delivery made F.O.B. HHI's place of business for U.S. customers or FCA HHI's U.S. location for international customers under Incoterms 2010; no warranty claim will be honored without valid proof of purchase, the customer must obtain a Return Goods Authorization before shipping the product freight-prepaid along with an explanation of the complaint, repaired products remain covered for the rest of the original warranty period, replacement parts installed after the original warranty period carry only a one-year replacement warranty (not including installation) from installation, and if no defect is found or the defect falls outside the warranty's scope, the customer is responsible for return shipping costs. HHI disclaims all other express or implied warranties, including merchantability or fitness for a particular purpose, and will not be liable for death, personal injury, property damage, or incidental, contingent, special, or consequential damages, losses, or expenses arising from the use or misuse of its products, regardless of whether such damage results from any act or failure to act by HHI, whether negligent, willful, or otherwise.
