EQ Electric Chain Hoist Lift-Capacity 1/4 Ton EQ003SD Electric Chain Hoist HARRINGTON

Write a Review
$3,383.39 - $3,638.86
SKU: EQ003SD-10
Condition: New
Availability: In stock
Weight: 71.00 LBS
Shipping: Free Shipping
Part Number: EQ003SD
Color: Yellow
Hoist Lift: 10, 15, 20
Product: Electric Chain Hoist, 500 lb. Hook Mounted-No Trolley, Yellow Hoist Mount Hook Mounted-No Trolley
Includes: Chain Container
Lift Speed: 33/5.5 fpm
Housing Width: 14 13/32 in
Manufacturers Warranty Length: 3 yr
Housing Depth: 9 7/64 in
Housing Length: 17 19/64 in
For Minimum Beam Flange Width: Not Applicable
For Maximum Beam Flange Width: Not Applicable
For Maximum Beam Height: Not Applicable
MFR Warranty Length: 3 yr
Body Width: 14 13/32 in
Body Depth: 9 1/8 in
For Minimum Beam Height: 15 in
Body Length: 17 5/16 in
Minimum Radius Curve: 10 in
Maximum Lifting Length: 20 ft
Controller Cord Length: 6 ft
Trolley Wheel Diameter: Not Applicable
Lifting Hook Opening Width: 1 3/32 in
Minimum Retracted Length: 17 5/16 in
Load Capacity: 500 lb.
Minimum Between Hooks: 17 5/16 in
Motor HP: 0.67 hp
Phase: 3
Standards: ASME HST-4, C22.2 No.33/14-13/66, CSA, UL 508A
Voltage: 460V
Fits Brand: Harrington Hoists Inc
Lubrication: Oil Bath
Reeving: 1
Thermal Protection: Yes
Control Cord: 6 ft
Amps @ Low Volts: 2.9 A
Number of Speeds: 2
Trolley Configuration: Hook/Suspension Bar Mounted
Trolley Speed: Not Applicable
Features: Extreme-Duty, Fan-Cooled Motor, No-Load High Speed, Self-Adjusting Maintenance-Free Brake, Unique Chain Guide, Variable Frequency Drive (VFD)
Lifting Hook Material: Carbon Steel
Includes Clutch: Clutch Included
Overload Protection Included: Yes
Brake Type: Pull Rotor
Chain Grade: Grade 80
Maximum Lift Speed: 33 fpm
Included Components: Chain Container, Pendant, Safety Latch Hook
Fixed Lift Speed: Not Applicable
Clutch Type: Friction
Minimum Lift Speed: 5.5 fpm
Pendant IP Rating: IP65
Chain Finish: Nickel Plated
Controls: Programmable by Internal Controls=Mount Type=Hook Mounted-No Trolley
Starts and Stops per Hour: 120, 240
Duty Classification: H4
Maximum Pulling Capacity: Not Applicable
Number of Reeves: 1
Motor Horsepower: 5/8 hp
Headroom: 17 5/16 in
Includes Brake: Brake Included
For Outdoor Use: Yes
Hoist IP Rating: IP55
Lifting Hook Type: Swivel Hook with Safety Latch
Maximum Lifting Capacity: 500 lb
Current at Minimum Voltage: 5.1 A
Trolley Wheel Material: Not Applicable
Current at Maximum Voltage: 2.8 A
Body Finish: Epoxy Painted
Number of Load Chains: 1
Body Material: Aluminum
Trolley IP Rating: Not Applicable
Programmable: Programmable by Internal Controls
Adding to cart… The item has been added
EQ Electric Chain Hoist Lift-Capacity 1/4 Ton EQ003SD Electric Chain Hoist HARRINGTON

EQ Electric Chain Hoist Lift-Capacity 1/4 Ton EQ003SD Electric Chain Hoist HARRINGTON

$3,383.39 - $3,638.86

EQ Electric Chain Hoist Lift-Capacity 1/4 Ton EQ003SD Electric Chain Hoist HARRINGTON

$3,383.39 - $3,638.86

Optimize your lifting operations with the EQ Electric Chain Hoist Lift-Capacity 1/4 Ton EQ003SD from HARRINGTON, designed for unmatched efficiency and reliability in industrial settings.

This electric chain hoist is engineered to handle medium to heavy-duty tasks with ease, making it the perfect addition to any factory, construction site, or warehouse. With its dual-speed Variable Frequency Drive (VFD) and robust 3-phase motor, the EQ003SD guarantees smooth, precise, and safe lifting operations every time, regardless of the load.

  • Capacity: 1/4 ton, providing versatility for both light and heavier loads.
  • Dual-Speed VFD: Ensures enhanced speed control for various lifting needs.
  • Durable Construction: Manufactured to withstand heavy usage in demanding environments.
  • Trusted Brand: HARRINGTON is recognized for high-quality, reliable lifting solutions.
  • Compact Design: Ideal for space-constrained work areas without compromising on performance.
  • Enhanced Productivity: Streamlines operations, allowing for efficient material handling.

The EQ003SD-10 is meticulously designed to enhance control and accuracy, ensuring that operators can lift and maneuver loads with minimal effort. Its advanced features provide the reliability and strength required for today's demanding industrial applications. This is not just a piece of equipment; it transforms manual labor into a seamless operation, thus improving productivity significantly.

Built with the highest quality materials, the EQ003SD is engineered for long-lasting performance. Users can trust in its ability to deliver consistent results day after day, making it an essential tool for any professional environment. HARRINGTON commitment to quality ensures that you have a hoist that is as dependable as it is capable, providing peace of mind on every lift.

Investing in the EQ003SD HARRINGTON EQ Electric Chain Hoist means investing in the efficiency of your operations. Experience superior lifting power, exceptional reliability, and the unmatched performance that comes with a leading electric chain hoist. Elevate your workload with the EQ003SD and discover how this powerful tool can make a difference in your operations.

Buyer must notify HHI in writing within sixty (60) days of discovery of any alleged defect, if within the applicable warranty period. All products sold by HHI are warranted to be free from defects in material and workmanship from date of shipment by HHI for the following periods: 1 year – Electric and Air Powered Hoists (excluding (N)ER2 Hoists and EQ/SEQ Hoists), Powered Trolleys, Powered Tiger Track Jibs and Gantries, Crane Components, Below the Hook Devices, Spare / Replacement Parts 2 years – Manual Hoists & Trolleys, Beam Clamps 3 years – (N)ER2 Hoists, EQ/SEQ Hoists, (T)EM/(T)SEM hoists, and RY Hoists 5 years – Manual Tiger Track Jibs and Gantries, Hoist Motor Brakes for EQ/SEQ, (T)EM/(T)SEM, and RY 10 years – (N)ER2 Brake, TNER Hoist Motor Brake The product must be used in accordance with manufacturer’s recommendations and must not have been subject to abuse, lack of maintenance, misuse, negligence, or unauthorized repairs or alterations. Should any defect in material or workmanship occur during the above time period in any product, as determined by HHI’s inspection of the product, HHI agrees, at its discretion, either to replace (not including installation) or repair the part or product free of charge. For customers in the U.S., delivery shall be made F.O.B. HHI’s place of business. For international customers, delivery shall be made FCA HHI place of business, United States of America (Incoterms 2010). No warranty claim will be honored without a valid proof of purchase. Customer must obtain a Return Goods Authorization as directed by HHI or its published repair center prior to shipping product for warranty evaluation. An explanation of the complaint must accompany the product. Product must be returned freight prepaid. Upon repair, the product will be covered for the remainder of the original warranty period. Replacement parts installed after the original warranty period will only be eligible for replacement (not including installation) for a period of one year from the installation date. If it is determined there is no defect, or that the defect resulted from causes not within the scope of HHI’s warranty, the customer will be responsible for the costs of returning the product. HHI DISCLAIMS ANY AND ALL OTHER WARRANTIES OF ANY KIND, EXPRESSED OR IMPLIED, AS TO THE PRODUCT’S MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. HHI WILL NOT BE LIABLE FOR DEATH, INJURIES TO PERSONS OR PROPERTY OR FOR INCIDENTAL, CONTINGENT, SPECIAL OR CONSEQUENTIAL DAMAGES, LOSS OR EXPENSE ARISING IN CONNECTION WITH THE USE OR MISUSE OF THE PRODUCTS, REGARDLESS OF WHETHER THE DAMAGE, LOSS OR EXPENSE RESULTS FROM ANY ACT OR FAILURE TO ACT BY HHI, WHETHER NEGLIGENT OR WILLFUL, OR FROM ANY OTHER CAUSE.
