Elevate your material handling capabilities with the DB22A29-13-DB11A41-26 Top Running Double Girder Crane. Engineered for heavy-duty performance, this crane seamlessly integrates a main and auxiliary lift system, making it the ideal solution for indoor industrial environments.

Designed with versatility in mind, the main configuration boasts a robust capacity of 11.00 tons and the auxiliary configuration supports 5.50 tons. This capacity ensures that you can handle a wide range of load sizes safely and efficiently, whether for heavy machinery or lighter materials.

• **Main and Auxiliary Hoist Design:** Combining a main hoist system with a 4-part reeving and an auxiliary system with a 2-part reeving, this crane guarantees true vertical lift and dual functionality for diverse operations.
• **Hoist Lift Speed:** The main hoist operates at a reliable lift speed of 13.00 feet per minute, while the auxiliary configuration accelerates loading operations with its impressive 26.00 feet per minute speed.
• **High-Performance Motors:** Each hoist configuration is powered by a strong 7.5 kW hoist motor, delivering exceptional lifting performance. Trolley operations are synchronized by two efficient 0.75 kW trolley motors.
• **Advanced Control Technology:** Featuring closed-loop vector Variable Frequency Drive (VFD) control ensures smooth handling of loads with precise adjustments to speed and torque.
• **Swift Trolley Movement:** Achieving a maximum trolley speed of 80.00 feet per minute, this crane allows for rapid horizontal transport of loads along the crane span.
• **Robust Structure and Design:** Built to endure, the crane's structure weighs approximately 3900.00 lbs and is equipped with premium-grade components for durability, including graphite ductile iron wheels and sheaves.
• **CMAA Class D Compliance:** Designed for indoor service in strict atmospheric conditions, the crane meets CMAA Class specifications, ensuring a safe and compliant operation.
• **Power Supply Compatibility:** Operates on a standard electric power supply of 460VAC, 3-phase, 60Hz, making it suitable for industrial electrical systems.
• **Enhanced Safety Features:** Over-weight protection through frequency drives, dynamic braking, and adjustable upper and lower electronic encoder limits maximize safety during operation.

Maximize your operational efficiency and ensure safety in your industrial environment with the DB22A29-13-DB11A41-26 Top Running Double Girder Crane. Experience unparalleled lift capabilities and technological innovation designed for rigorous material handling tasks. Let this crane embody reliability in your daily operations.
