Detroit Hoist Top Running Double Girder Crane (Low Profile), 16.5 Ton Capacity, 16 FPM Lift Speed, 80 FPM Trolley Speed, 84" Trolley Gauge, Model DB33LH20-16

Write a Review
$35,000.00
$30,625.00
(You save $4,375.00 )
SKU: DB33LH20-16
Weight: 2,100.00 LBS
Shipping: Calculated at Checkout
Capacity: 30,000 - 39,999 lbs
Lift: 20.2 ft
Mounting: Top Running
Configuration: Double Girder
Voltage: 230/3/60
Adding to cart… The item has been added
Detroit Hoist Top Running Double Girder Crane (Low Profile), 16.5 Ton Capacity, 16 FPM Lift Speed, 80 FPM Trolley Speed, 84" Trolley Gauge, Model DB33LH20-16

Detroit Hoist Top Running Double Girder Crane (Low Profile), 16.5 Ton Capacity, 16 FPM Lift Speed, 80 FPM Trolley Speed, 84" Trolley Gauge, Model DB33LH20-16

$35,000.00
$30,625.00
(You save $4,375.00 )

Detroit Hoist Top Running Double Girder Crane (Low Profile), 16.5 Ton Capacity, 16 FPM Lift Speed, 80 FPM Trolley Speed, 84" Trolley Gauge, Model DB33LH20-16

$35,000.00
$30,625.00
(You save $4,375.00 )

Engineered for exceptional performance, the Top Running Double Girder Low Profile crane is a robust lifting solution designed for industrial environments. With a powerful capacity of 16.50 tons and ample speed, this crane excels in material handling tasks while minimizing space requirements, making it perfect for facilities with limited vertical clearance.

This crane features a top-running double girder low-profile suspension, delivering tremendous support for lifting operations. The configuration is specifically designed to operate efficiently in confined areas, allowing for seamless integration into various workflows. Its 4 part line reeving system enables a lift height of 20'­2", accommodating a range of load requirements while ensuring precise vertical movement.

  • Capacity: 16.50 tons for diverse industrial applications.
  • Hoist lift speed of 16.00 FPM for fast vertical movement.
  • Maximum trolley speed of 80.00 FPM for efficient horizontal load transport.
  • Hoist powered by a 13.4 KW motor for reliable performance.
  • Closed-loop vector Variable Frequency Drive (VFD) for precise control.
  • Sensorless vector VFD control for accurate trolley maneuvering.
  • Durable construction with premium grade graphite ductile iron wheels.
  • Designed for 230VAC, 3-phase, 60Hz electric power supply.
  • CMAA Class D classification for standard weather-resistant service.
  • Trolley gauge of 84.0000 inches for optimal spacing and movement.

Weighing approximately 2,100 lbs, the Top Running Double Girder Low Profile crane is easy to install and maneuver, ensuring a swift transition to operational excellence. The innovative features include dynamic braking and motor overload protection, along with adjustable electronic limits for enhanced safety and reliability.

The Company warrants the equipment against defects in material and workmanship for one (1) year from the date of shipment, provided operation is maintained within Class D service conditions, and will replace free of charge, F.O.B. its manufacturing plant, any part (other than wire rope or rope guide rings) found defective, provided the purchaser immediately informs the Company of the defect and no repairs or alterations have been performed by the purchaser or a third party without the Company's written approval; this warranty excludes normal wear and parts inherently subject to premature wear, and the Company is not responsible for phase reversal on the connected power station network, nor liable for damages caused by improper installation or use, lifting loads above rated capacity, or consequential damages, claims, expenditures, or losses arising from operational delays or work stoppages caused by defective equipment. All repairs during the warranty period must be authorized by the Company, and the warranty applies only if the purchaser provides a signed Equipment Certification Form certifying that the equipment has been properly installed, tested, and is in satisfactory working order; the warranty excludes damage caused by improper storage, installation, unauthorized repairs, misuse, improper wiring or electrical service, improper handling, overloading, unsuitable fuels or oils, improper modifications or maintenance, faulty construction or foundations, unsuitable building grounds, chemical/electro-chemical/electrical influences, or other circumstances beyond the Company's fault, and all warranties become null and void if the purchaser or any subsequent user engages in such improper conduct or if such circumstances occur, in which case the Company is free of all obligations, costs, and liabilities under the warranty. All warranties extend only to the purchaser in privity of contract with the Company, and the purchaser - not the Company - is solely responsible for informing equipment users of all warranty and liability limitations; except as stated, no express, implied, or statutory warranty is made by the Company, and the Company is free of any warranty obligations should the purchaser default on agreed payment terms.
