Detroit Hoist Monorail Hoist, 16.5 Ton Capacity, 16 FPM Lift Speed, 80 FPM Trolley Speed, Model DB33M38-16
DB33M38- 16
video
Detroit Hoist Monorail Hoist, 16.5 Ton Capacity, 16 FPM Lift Speed, 80 FPM Trolley Speed, Model DB33M38-16
DB33M38- 16

  • Guaranteed Fitment

    Always the correct part

  • In-House Experts

    We know our products

  • Added Value

    FREE in house engineering and design assistance

  • Wordwide Delivery

    Free shipping on all Harrington orders over 500LBS

Detroit Hoist Monorail Hoist, 16.5 Ton Capacity, 16 FPM Lift Speed, 80 FPM Trolley Speed, Model DB33M38-16

Write a Review
$29,000.00
$25,375.00
(You save $3,625.00 )
SKU: DB33M38-16
Weight: 2,000.00 LBS
Shipping: Calculated at Checkout
Adding to cart… The item has been added
Detroit Hoist Monorail Hoist, 16.5 Ton Capacity, 16 FPM Lift Speed, 80 FPM Trolley Speed, Model DB33M38-16

Detroit Hoist Monorail Hoist, 16.5 Ton Capacity, 16 FPM Lift Speed, 80 FPM Trolley Speed, Model DB33M38-16

$29,000.00
$25,375.00
(You save $3,625.00 )

Detroit Hoist Monorail Hoist, 16.5 Ton Capacity, 16 FPM Lift Speed, 80 FPM Trolley Speed, Model DB33M38-16

$29,000.00
$25,375.00
(You save $3,625.00 )
Description

The DB33M38-16 Monorail System is engineered for exceptional performance and reliability in heavy-duty industrial applications. Designed to address the diverse needs of modern material handling, this cutting-edge hoisting solution maximizes efficiency and operational safety with its robust specifications.

With a remarkable lifting capacity of 16.50 tons, the DB33M38-16 Monorail meets the rigorous demands of heavy material movement. Its versatile installation configurations allow it to adapt seamlessly to various operational environments, making it an ideal choice for warehouses, manufacturing facilities, and other industrial settings.

  • Impressive 16.50-ton lifting capacity ensures reliability in material handling tasks.
  • Utilizes a 4-part reeving system for a lift height of up to 38 feet, providing significant vertical reach.
  • Maximum lift speed of 16.00 feet per minute promotes swift and controlled load movement.
  • Powered by a 13.4 kW hoist motor for smooth and reliable lifting performance.
  • Closed-loop vector Variable Frequency Drive (VFD) control enhances speed and torque regulation.
  • Trolley speed of 80.00 FPM enables efficient horizontal load transportation.
  • Equipped with dual 0.55 kW trolley motors for precise lateral movement.
  • Sensorless vector VFD control for smooth acceleration and accurate positioning of loads.
  • Operates on standard electric power supply (230VAC, 3-phase, 60Hz) for seamless integration.
  • Compliant with CMAA Class D standards, ensuring reliability in standard atmospheric conditions.
  • Durable construction weighing approximately 2000.00 lbs, maintaining structural integrity during operation.
  • Premium grade graphite ductile iron wheels and sheaves provide outstanding durability.
  • UL508A listed industrial control panel for added safety and compliance.
  • Dynamic braking features for precise control and load protection.
  • Adjustable electronic encoder limits for upper and lower range regulation.

The DB33M38-16 Monorail System combines advanced engineering with thoughtful features, making it the ultimate choice for businesses seeking to enhance their operational efficiency and material handling capabilities. Trust in this robust system to deliver reliable performance and unmatched safety in your industrial operations.

Warranty Information
The Company warrants the equipment against defects in material and workmanship for one (1) year from the date of shipment, provided operation is maintained within Class D service conditions, and will replace free of charge, F.O.B. its manufacturing plant, any part (other than wire rope or rope guide rings) found defective, provided the purchaser immediately informs the Company of the defect and no repairs or alterations have been performed by the purchaser or a third party without the Company's written approval; this warranty excludes normal wear and parts inherently subject to premature wear, and the Company is not responsible for phase reversal on the connected power station network, nor liable for damages caused by improper installation or use, lifting loads above rated capacity, or consequential damages, claims, expenditures, or losses arising from operational delays or work stoppages caused by defective equipment. All repairs during the warranty period must be authorized by the Company, and the warranty applies only if the purchaser provides a signed Equipment Certification Form certifying that the equipment has been properly installed, tested, and is in satisfactory working order; the warranty excludes damage caused by improper storage, installation, unauthorized repairs, misuse, improper wiring or electrical service, improper handling, overloading, unsuitable fuels or oils, improper modifications or maintenance, faulty construction or foundations, unsuitable building grounds, chemical/electro-chemical/electrical influences, or other circumstances beyond the Company's fault, and all warranties become null and void if the purchaser or any subsequent user engages in such improper conduct or if such circumstances occur, in which case the Company is free of all obligations, costs, and liabilities under the warranty. All warranties extend only to the purchaser in privity of contract with the Company, and the purchaser - not the Company - is solely responsible for informing equipment users of all warranty and liability limitations; except as stated, no express, implied, or statutory warranty is made by the Company, and the Company is free of any warranty obligations should the purchaser default on agreed payment terms.
