Detroit Hoist Top Running Double Girder Crane (Low Profile), 11 Ton Capacity, 13 FPM Lift Speed, 80 FPM Trolley Speed, 78" Trolley Gauge, Model DB22LH20-13
DB22LH20-13
Detroit Hoist Top Running Double Girder Crane (Low Profile), 11 Ton Capacity, 13 FPM Lift Speed, 80 FPM Trolley Speed, 78" Trolley Gauge, Model DB22LH20-13
DB22LH20-13

  • Guaranteed Fitment

    Always the correct part

  • In-House Experts

    We know our products

  • Added Value

    FREE in house engineering and design assistance

  • Wordwide Delivery

    Free shipping on all Harrington orders over 500LBS

Detroit Hoist Top Running Double Girder Crane (Low Profile), 11 Ton Capacity, 13 FPM Lift Speed, 80 FPM Trolley Speed, 78" Trolley Gauge, Model DB22LH20-13

Write a Review
$28,000.00
$24,500.00
(You save $3,500.00 )
SKU: DB22LH20-13
Weight: 1,800.00 LBS
Shipping: Calculated at Checkout
Capacity: 20,000 - 29,999 lbs
Lift: 20.2 ft
Mounting: Top Running
Configuration: Double Girder
Voltage: 230/3/60
Adding to cart… The item has been added
Detroit Hoist Top Running Double Girder Crane (Low Profile), 11 Ton Capacity, 13 FPM Lift Speed, 80 FPM Trolley Speed, 78" Trolley Gauge, Model DB22LH20-13

Detroit Hoist Top Running Double Girder Crane (Low Profile), 11 Ton Capacity, 13 FPM Lift Speed, 80 FPM Trolley Speed, 78" Trolley Gauge, Model DB22LH20-13

$28,000.00
$24,500.00
(You save $3,500.00 )

Detroit Hoist Top Running Double Girder Crane (Low Profile), 11 Ton Capacity, 13 FPM Lift Speed, 80 FPM Trolley Speed, 78" Trolley Gauge, Model DB22LH20-13

$28,000.00
$24,500.00
(You save $3,500.00 )
Description

The Top Running Double Girder Low Profile hoist, model DB22LH20-13 from Detroit, is engineered to exceed the demands of modern industrial lifting operations. With an impressive lifting capacity of 11.00 tons and the capability to operate in tight spaces, this hoist provides an optimal solution for efficiency and safety even in challenging environments.

Designed for versatility, the Top Running Double Girder Low Profile offers a robust support structure while maintaining a sleek, low-profile design. This model is perfect for installations with limited vertical space where reliability is paramount. Its advanced hoisting capabilities, combined with its impressive specifications, make it an ideal choice for a variety of heavy-duty applications.

  • Capacity: Lifts loads up to 11.00 tons, making it suitable for medium to heavy lifting tasks.
  • Reeving/Lift: Features a 4-part line reeving system for a specific lift height of 20'­2", providing adaptability for diverse load sizes.
  • Hoist Lift Speed: Operates at a maximum speed of 13.00 feet per minute (FPM), ensuring efficient vertical movement of materials.
  • Motor: Powered by a 7.5 kW motor, delivering dependable performance during demanding lifting operations.
  • Control System: Includes closed-loop vector Variable Frequency Drive (VFD) control for precise and responsive operations, enhancing load safety and positioning accuracy.
  • Trolley Speed: Capable of reaching 80.00 FPM for quick horizontal movement across work sites.
  • Trolley Motor: Comes with two reliable motors rated at 0.55 kW, ensuring consistent performance along runways.
  • Trolley Control: Incorporates sensorless vector VFD control for smooth maneuvering, boosting operational efficiency.
  • Power Supply Compatibility: Operates on standard 230VAC, 3-phase, 60Hz power supplies with a tolerance of ±5% for universal applicability.
  • CMAA Class D rating: Suitable for standard weather-resistant service, ensuring durability in various atmospheric conditions.
  • Trolley Gauge: Offers a trolley gauge of 78 inches, providing ample clearance for smooth operation along runway beams.
  • Weight: Weighs approximately 1800 lbs, designed for uncomplicated installation while maintaining structural integrity.

The Top Running Double Girder Low Profile hoist model DB22LH20-13 exemplifies a perfect blend of power, precision, and performance. Equip your facility with this outstanding hoisting solution to elevate your lifting capabilities and enhance your operational efficiency.

Warranty Information
The Company warrants the equipment against defects in material and workmanship for one (1) year from the date of shipment, provided operation is maintained within Class D service conditions, and will replace free of charge, F.O.B. its manufacturing plant, any part (other than wire rope or rope guide rings) found defective, provided the purchaser immediately informs the Company of the defect and no repairs or alterations have been performed by the purchaser or a third party without the Company's written approval; this warranty excludes normal wear and parts inherently subject to premature wear, and the Company is not responsible for phase reversal on the connected power station network, nor liable for damages caused by improper installation or use, lifting loads above rated capacity, or consequential damages, claims, expenditures, or losses arising from operational delays or work stoppages caused by defective equipment. All repairs during the warranty period must be authorized by the Company, and the warranty applies only if the purchaser provides a signed Equipment Certification Form certifying that the equipment has been properly installed, tested, and is in satisfactory working order; the warranty excludes damage caused by improper storage, installation, unauthorized repairs, misuse, improper wiring or electrical service, improper handling, overloading, unsuitable fuels or oils, improper modifications or maintenance, faulty construction or foundations, unsuitable building grounds, chemical/electro-chemical/electrical influences, or other circumstances beyond the Company's fault, and all warranties become null and void if the purchaser or any subsequent user engages in such improper conduct or if such circumstances occur, in which case the Company is free of all obligations, costs, and liabilities under the warranty. All warranties extend only to the purchaser in privity of contract with the Company, and the purchaser - not the Company - is solely responsible for informing equipment users of all warranty and liability limitations; except as stated, no express, implied, or statutory warranty is made by the Company, and the Company is free of any warranty obligations should the purchaser default on agreed payment terms.
