ALR Titon Electric Chain Hoist – 2 Ton Capacity | 20-Foot Lift | Three-Phase

Product Overview

Atlas Titon Electric Chain Hoist – TEH-3-020-20

2 Ton Capacity | 20-Foot Lift | Three-Phase | Single Speed

The Atlas TEH-3-020-20 Titon Electric Chain Hoist is a reliable and efficient lifting solution for demanding overhead applications. With a 2-ton (4,400 lbs) capacity and 20-foot lift height, this hoist is ideal for operations requiring both strength and extended vertical reach. Built for industrial use, it features a robust motor, high-strength load chain, and safety-focused components designed for long service life in challenging environments.

Features

• 2 Ton Rated Capacity: Designed for lifting heavy materials up to 4,400 lbs safely and efficiently.
• 20-Foot Lift Height: Provides extended reach for tall structures, loading bays, or elevated installations.
• Durable Load Chain: Grade 80 alloy steel with black oxide coating for added duribilty and corrosion resistance.
• Three-Phase Industrial Motor: Delivers consistent lifting power; equipped with thermal overload protection.
• Electromagnetic Load Brake: Ensures secure load holding during operation and power loss.
• 24V Pendant Control: Low-voltage, ergonomic push-button pendant for enhanced operator safety and control.
• Top Hook Suspension: Forged steel hook for stable and secure mounting to fixed or mobile support systems.
• IP54 Enclosure Rating: Protects internal components from environmental exposure.

Specifications

• Model: TEH-3-020-20
• Rated Capacity: 2 Ton (4,400 lbs)
• Lift Height: 20 feet
• Lifting Speed: Approx. 8–10 feet per minute (single speed)
• Load Chain: Grade 80 alloy steel, black oxide finish
• Brake Type: Electromagnetic
• Motor Protection: Thermal overload protection
• Pendant Control: 24V low-voltage, push-button
• Suspension: Top hook
• Enclosure Protection: IP54 (dust and splash resistant)
• Duty Cycle: 30% ED (intermittent use)
• Power Supply: Three-phase (voltage specified at order)
• Approximate Weight: 200–220 lbs
• Warranty: 3-Year Limited
• Country of Origin: China

The TEH-3-020-20 is a dependable and high-performing electric hoist, purpose-built for extended lift operations across manufacturing, construction, and heavy equipment handling environments.
