NERP Electric Chain Hoist with Push Trolley 20' Lift-Capacity 10 Tons NERP100L Electric Chain Hoist with Push Trolley HARRINGTON

Product Overview

Upgrade your workshop with the NERP100L-20 HARRINGTON NERP Electric Chain Hoist with Push Trolley. This powerful and reliable electric hoist and push trolley combination is perfect for small workshops and occasional moves. With its impressive lifting capacity 10 Tons and a generous 20' lift, it effortlessly handles heavy loads with ease.The NERP100L-20 is equipped with a PT push trolley that enables smooth and efficient transport of your load, streamlining your workflow. This push trolley is designed to glide effortlessly along the beam, allowing for easy positioning and movement of your load. Whether you need to lift heavy machinery, equipment, or materials, this hoist and trolley combination ensures smooth and precise lifting and transportation.Engineered with Harrington's renowned quality and reliability, this electric chain hoist is built to last. It is constructed with durable materials and equipped with safety features to guarantee safe and secure lifting operations. The sturdy construction and robust design ensure stability and minimize the risk of accidents or damage during lifting and transportation.The NERP100L-20 offers unparalleled performance and convenience. It provides precise control and smooth operation, thanks to its advanced chain and trolley system. The hoist is easy to operate, making it suitable for both experienced professionals and users new to hoist equipment.Whether you're a small workshop owner, an industrial facility manager, or a professional contractor, the NERP100L-20 HARRINGTON NERP Electric Chain Hoist with Push Trolley is an essential tool for your lifting and transportation needs. Its versatility, reliability, and ease of use ensure that you can complete your jobs efficiently and safely.Upgrade your workshop today with the NERP100L-20 HARRINGTON NERP Electric Chain Hoist with Push Trolley and experience the difference in performance and convenience. Elevate your lifting operations and make heavy lifting a breeze. Trust in Harrington's reputation for quality and reliability. Invest in the NERP100L-20 and take your workshop to the next level.

Product Specifications

.

Part Number:

NERP100L-20

Color:

Yellow

Hoist Lift:

20 ft

Product:

Electric Chain Hoist, 20,000 lb, 20 ft, Push Trolley=Hoist Mount=Push Trolley

Includes:

10 Year Brake Warranty, Chain Container, Push Trolley, Quick Disconnect Plugs On Pendant And Power Cords

Lift Speed:

5.5 fpm

Housing Width:

13 1/4 in

Manufacturers Warranty Length:

10 yr Brake Warranty, 3 yr

Housing Depth:

10 1/2 in

Housing Length:

28 7/8 in

For Minimum Beam Flange Width:

5 1/2 in

For Maximum Beam Flange Width:

8 21/32 in

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

13 1/4 in

Body Depth:

10 1/2 in

For Minimum Beam Height:

7 5/16 in

Body Length:

28 7/8 in

Minimum Radius Curve:

118 3/32 in

Maximum Lifting Length:

20 ft

Controller Cord Length:

16 ft

Trolley Wheel Diameter:

7 3/10 in

Lifting Hook Opening Width:

3 3/16 in

Minimum Retracted Length:

46 1/2 in

Load Capacity:

20,000 lb

Minimum Between Hooks:

46 1/2 in

Motor HP:

4.7 hp

Phase:

3

Standards:

ANSI/ASME B30.16, ASME HST-1M, NFPA 70, RoHS Compliant, UL 1340

Voltage:

208/230/460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Item:

Electric Chain Hoist

Reeving:

4

Thermal Protection:

Yes

Control Cord:

16 ft

Amps @ Low Volts:

16.4 A

Number of Speeds:

1

Trolley Configuration:

Push Trolley

Trolley Speed:

Not Applicable

Features:

Count Hour Meter, Extreme Duty Motor, Push Trolley, Smart Brake Technology

Material:

Die Cast Aluminum

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

DC Current

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

5.5 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Push Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

4

Motor Horsepower:

4 3/4 hp

Headroom:

46 1/2 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

20,000 lb

Current at Minimum Voltage:

16.4 A

Trolley Wheel Material:

Steel

Current at Maximum Voltage:

7.9 A

Body Finish:

Enamel

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
