NERP Electric Chain Hoist with Push Trolley 15' Lift-Capacity 10 Tons NERP100L Electric Chain Hoist with Push Trolley HARRINGTON

Product Overview

The NERP100L-15 HARRINGTON Electric Chain Hoist with Push Trolley is a robust lifting solution designed for both professionals and enthusiasts alike. With an impressive 10-ton capacity and a 15-foot lift, this electric chain hoist simplifies lifting heavy loads across your workshop or job site.

Engineered for both reliability and efficiency, the NERP100L-15 makes lifting tasks seamless. The accompanying push trolley offers smooth maneuverability and precise control, allowing users to transport materials or heavy machinery effortlessly. This feature is particularly advantageous for those who require mobility and flexibility in their operations, making it ideal for small spaces and infrequent lifting tasks.

Construction quality is a hallmark of the HARRINGTON brand, ensuring that this electric chain hoist not only meets but exceeds industry standards. Designed with user convenience in mind, the hoist operates silently while delivering powerful performance, enabling you to handle any lifting job with confidence.

Furthermore, the NERP100L-15 promotes an economical approach to load transportation, significantly reducing the physical strain associated with manual lifting. Say goodbye to tedious and dangerous lifting methods; this innovative hoist enhances workplace safety, letting you focus on the task at hand.

Durability is also assured, as the NERP100L-15 is built to withstand the rigors of frequent use. This means that your investment will pay off in years of dependable performance. Whether you're lifting motor parts for a project or moving materials in a garage, this hoist transforms your lifting operations into an efficient and hassle-free experience.

Embrace the power and versatility of the NERP100L-15 HARRINGTON Electric Chain Hoist with Push Trolley. Elevate your operational capabilities today and enjoy the convenience and efficiency it brings to your daily tasks.

Product Specifications

.

Part Number:

NERP100L-15

Color:

Yellow

Hoist Lift:

15 ft

Product:

Electric Chain Hoist, 20,000 lb, 15 ft, Push Trolley=Hoist Mount=Push Trolley

Includes:

10 Year Brake Warranty, Chain Container, Push Trolley, Quick Disconnect Plugs On Pendant And Power Cords

Lift Speed:

5.5 fpm

Housing Width:

13 1/4 in

Manufacturers Warranty Length:

10 yr Brake Warranty, 3 yr

Housing Depth:

10 1/2 in

Housing Length:

28 7/8 in

For Minimum Beam Flange Width:

5 1/2 in

For Maximum Beam Flange Width:

8 21/32 in

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

13 1/4 in

Body Depth:

10 1/2 in

For Minimum Beam Height:

7 5/16 in

Body Length:

28 7/8 in

Minimum Radius Curve:

118 3/32 in

Maximum Lifting Length:

15 ft

Controller Cord Length:

11 ft

Trolley Wheel Diameter:

7 3/10 in

Lifting Hook Opening Width:

3 3/16 in

Minimum Retracted Length:

46 1/2 in

Load Capacity:

20,000 lb

Minimum Between Hooks:

46 1/2 in

Motor HP:

4.7 hp

Phase:

3

Standards:

ANSI/ASME B30.16, ASME HST-1M, NFPA 70, RoHS Compliant, UL 1340

Voltage:

208/230/460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

4

Thermal Protection:

Yes

Control Cord:

11 ft

Amps @ Low Volts:

16.4 A

Number of Speeds:

1

Trolley Configuration:

Push Trolley

Trolley Speed:

Not Applicable

Features:

Count Hour Meter, Extreme Duty Motor, Push Trolley, Smart Brake Technology

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

DC Current

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

5.5 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Push Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

4

Motor Horsepower:

4 3/4 hp

Headroom:

46 1/2 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

20,000 lb

Current at Minimum Voltage:

16.4 A

Trolley Wheel Material:

Steel

Current at Maximum Voltage:

7.9 A

Body Finish:

Enamel

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
