NERP Electric Chain Hoist with Push Trolley 10' Lift-Capacity 1/4 Tons sNERP003S Electric Chain Hoist with Push Trolley HARRINGTON

Product Overview

The NERP003S-10 HARRINGTON NERP Electric Chain Hoist with Push Trolley 10' Lift is designed to provide smooth and efficient load transportation. Whether you need to lift heavy materials in a small workshop or require occasional moves, this hoist is the perfect solution. Its reliability and durability make it an essential tool in any lifting operation.By mounting the NERP003S Electric Chain Hoist onto the PT push trolley, you can easily and cost-effectively meet your lifting needs. The push trolley allows for easy maneuverability, ensuring that your loads can be transported effortlessly. No more struggling with manual lifting. With the NERP003S-10, you can streamline your lifting processes and improve productivity.This hoist is capable of handling a wide range of loads, with Capacity 1/4 Tons . This versatility makes it suitable for various applications, whether you need to lift heavy machinery or lighter materials. Its power and efficiency guarantee that your lifting needs will be met, no matter the size or weight of the load.Investing in the NERP003S-10 means investing in hassle-free transportation of your loads. Say goodbye to the physical strain of manual lifting and enjoy the convenience and ease of an electric chain hoist. With its reliable performance and sturdy construction, this hoist is built to withstand the demands of your lifting operations for years to come.In summary, the NERP003S-10 HARRINGTON NERP Electric Chain Hoist with Push Trolley 10' Lift is the ideal choice for anyone in need of a reliable and efficient lifting solution. Its versatility, durability, and ease of use make it a valuable addition to any workshop or lifting operation. Invest in this hoist today and experience the convenience of hassle-free load transportation.

Product Specifications

.

Part Number:

NERP003S-10

Color:

Yellow

Hoist Lift:

10 ft

Product:

Electric Chain Hoist, 500 lb, 10 ft, Push Trolley=Hoist Mount=Push Trolley

Includes:

10 Year Brake Warranty, Chain Container, Push Trolley, Quick Disconnect Plugs On Pendant And Power Cords

Lift Speed:

36 fpm

Housing Width:

13 11/16 in

Manufacturers Warranty Length:

10 yr Brake Warranty, 3 yr

Housing Depth:

6 5/8 in

Housing Length:

18 13/16 in

For Minimum Beam Flange Width:

2 1/4 in

For Maximum Beam Flange Width:

4 in

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

13 11/16 in

Body Depth:

6 5/8 in

For Minimum Beam Height:

3 in

Body Length:

18 13/16 in

Minimum Radius Curve:

43 5/16 in

Maximum Lifting Length:

10 ft

Controller Cord Length:

6 ft

Trolley Wheel Diameter:

3 1/5 in

Lifting Hook Opening Width:

1 3/32 in

Minimum Retracted Length:

15 19/32 in

Load Capacity:

500 lb

Minimum Between Hooks:

15 5/8 in

Motor HP:

0.75 hp

Phase:

3

Standards:

ANSI/ASME B30.16, ASME HST-1M, NFPA 70, RoHS Compliant, UL 1340

Voltage:

208/230/460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

1

Thermal Protection:

Yes

Classification:

H4

Control Cord:

6 ft

Amps @ Low Volts:

3.4 A

Number of Speeds:

1

Trolley Configuration:

Push Trolley

Trolley Speed:

Not Applicable

Features:

Count Hour Meter, Extreme Duty Motor, Push Trolley, Smart Brake Technology

Material:

Die Cast Aluminum

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

DC Current

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

36 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Programmable by Internal Controls=Mount Type=Push Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

3/4 hp

Headroom:

15 19/32 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

500 lb

Current at Minimum Voltage:

3.4 A

Trolley Wheel Material:

Steel

Current at Maximum Voltage:

1.7 A

Body Finish:

Enamel

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
