Product Overview
The NERM Electric Chain Hoist Motorized Trolley, model NERM100S-L-20, stands as a testament to robust engineering and efficiency in heavy lifting applications. With an impressive lift capacity of 10 tons and a 20-foot lift height, this electric chain hoist is built to tackle the most demanding tasks with remarkable ease. Whether you're moving heavy machinery or transporting bulky materials, the NERM100S-L-20 is designed to handle it all.What sets this hoist apart is its motorized trolley, ensuring smooth and precise movement across various setups, thereby enhancing productivity and safety on the job. The days of strenuous manual maneuvering are over; this hoist brings convenience and operational efficiency to your workflow. Its exceptional design guarantees reliable performance, whether in a congested warehouse or an expansive outdoor construction site.
Furthermore, the NERM100S-L-20 features a fully sealed, outdoor-rated construction, making it incredibly resilient against environmental factors. Dust, moisture, and extreme temperatures are no match for this heavy-duty hoist, ensuring that you can depend on it regardless of where you need to work.
Investing in the NERM100S-L-20 means opting for a product that prioritizes performance, durability, and safety. Say goodbye to equipment malfunctions and inefficiencies ‚this hoist is engineered to deliver reliable service, allowing you to focus on getting your tasks done seamlessly.
For those who require a powerful and dependable electric chain hoist with a motorized trolley, the NERM100S-L-20 Harrington model makes an ideal choice. Experience unmatched lifting capabilities that streamline your operations while maintaining utmost reliability, making heavy lifting easier than ever before. Choose the NERM100S-L-20 and elevate your productivity with confidence.
Product Specifications
.Product Videos
Videos Hide Videos Show Videos
Custom Field
Part Number NERM100S-L-20
Color Yellow
Hoist Lift 20 ft
Product Electric Chain Hoist, 20,000 lb, 20 ft, Motorized Trolley=Hoist Mount=Motorized Trolley
Includes Chain Container, Guardian Smart Brake, Motorized Trolley
Lift Speed 11 fpm
Housing Width 13 1/4 in
Manufacturers Warranty Length 10 yr Brake Warranty, 3 yr
Housing Depth 10 1/2 in
Housing Length 28 7/8 in
For Minimum Beam Flange Width 5 1/2 in
For Maximum Beam Flange Width 8 21/32 in
For Maximum Beam Height Not Applicable
MFR Warranty Length 1 yr
Body Width 13 1/4 in
Body Depth 10 1/2 in
For Minimum Beam Height 6 29/32 in
Body Length 28 7/8 in
Minimum Radius Curve 98 13/32 in
Maximum Lifting Length 20 ft
Controller Cord Length 16 ft
Trolley Wheel Diameter 6 9/10 in
Lifting Hook Opening Width 3 3/16 in
Minimum Retracted Length 46 1/2 in
Load Capacity 20,000 lb
Minimum Between Hooks 46 1/2 in
Motor HP 4.7 hp x2
Phase 3
Standards ANSI/ASME B30.16, ASME HST-1M, NFPA 70, RoHS Compliant, UL 1340
Voltage 208/230/460
Lubrication Oil Bath
Reeving 4
Thermal Protection Yes
Classification H4
Control Cord 16 ft
Amps @ Low Volts 16.4x2
Number of Speeds 1
Trolley Configuration Motorized Trolley
Trolley Speed 40 fpm
Features Dual Speed Trolley VFD, Rubber Bumpers, Side Guide Rollers
Lifting Hook Material Carbon Steel
Includes Clutch Clutch Included
Overload Protection Included Yes
Brake Type DC Current
Chain Grade Grade 80
Maximum Lift Speed Not Applicable
Included Components Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Rubber Bumpers, Safety Latch Hook
Fixed Lift Speed 11 fpm
Clutch Type Friction Clutch
Minimum Lift Speed Not Applicable
Pendant IP Rating IP65
Chain Finish Nickel Plated
Controls Push Button Pendant=Mount Type=Motorized Trolley
Starts and Stops per Hour 120, 240
Duty Classification H4
Maximum Pulling Capacity Not Applicable
Number of Reeves 4
Motor Horsepower 4 3/4 hp
Headroom 46 1/2 in
Includes Brake Brake Included
For Outdoor Use Yes
Hoist IP Rating IP55
Lifting Hook Type Swivel Hook with Safety Latch
Maximum Lifting Capacity 20,000 lb
Current at Minimum Voltage 5.1 A
Trolley Wheel Material Steel
Current at Maximum Voltage 1.7 A
Body Finish Enamel
Number of Load Chains 1
Body Material Aluminum
Trolley IP Rating IP55
Programmable Non-Programmable
