Product Overview
Upgrade your lifting capabilities with the NERM100S-L Electric Chain Hoist with Motorized Trolley by Harrington. This rugged and efficient hoist is designed to withstand the harshest conditions, ensuring reliable performance in even the most demanding applications.With a lift capacity 10 Tons , the NERM100S-L allows you to easily handle heavy loads with ease and precision. Whether you're working in construction, manufacturing, or any other industry that requires heavy lifting, this hoist is up to the task.Featuring a completely sealed and outdoor-rated design, the NERM100S-L is suitable for use in a wide range of environments. It can withstand dust, dirt, and water, ensuring long-lasting durability and performance. You can rely on this hoist to keep working efficiently, no matter the conditions.Say goodbye to manual lifting and embrace the power and convenience of the motorized trolley hoist. With the NERM100S-L, you can easily move heavy loads along the designated path, saving time and effort. This hoist is designed to streamline your operations and increase productivity.Invest in the NERM100S-L Electric Chain Hoist with Motorized Trolley and elevate your productivity to new heights. This hoist is built to withstand the toughest conditions, ensuring reliable performance every time. Its versatile lift capacity and outdoor-rated design make it a valuable asset in various industries.Don't let heavy lifting slow you down. Upgrade to the NERM100S-L and experience the convenience and power of a motorized trolley hoist. With Harrington's reputation for quality and reliability, you can trust that this hoist will meet and exceed your expectations. Take your lifting capabilities to new heights with the NERM100S-L Electric Chain Hoist with Motorized Trolley.Product Specifications
.Product Videos
Videos Hide Videos Show Videos
Custom Field
Part Number NERM100S-L-15
Color Yellow
Hoist Lift 15 ft
Product Electric Chain Hoist, 20,000 lb, 15 ft, Motorized Trolley=Hoist Mount=Motorized Trolley
Includes Chain Container, Guardian Smart Brake, Motorized Trolley
Lift Speed 11 fpm
Housing Width 13 1/4 in
Manufacturers Warranty Length 10 yr Brake Warranty, 3 yr
Housing Depth 10 1/2 in
Housing Length 28 7/8 in
For Minimum Beam Flange Width 5 1/2 in
For Maximum Beam Flange Width 8 21/32 in
For Maximum Beam Height Not Applicable
MFR Warranty Length 1 yr
Body Width 13 1/4 in
Body Depth 10 1/2 in
For Minimum Beam Height 6 29/32 in
Body Length 28 7/8 in
Minimum Radius Curve 98 13/32 in
Maximum Lifting Length 15 ft
Controller Cord Length 11 ft
Trolley Wheel Diameter 6 9/10 in
Lifting Hook Opening Width 3 3/16 in
Minimum Retracted Length 46 1/2 in
Load Capacity 20,000 lb
Minimum Between Hooks 46 1/2 in
Motor HP 4.7 hp x2
Phase 3
Standards ANSI/ASME B30.16, ASME HST-1M, NFPA 70, RoHS Compliant, UL 1340
Voltage 208/230/460
Lubrication Oil Bath
Reeving 4
Thermal Protection Yes
Control 110v
Control Cord 11 ft
Amps @ Low Volts 16.4x2
Number of Speeds 1
Trolley Configuration Motorized Trolley
Trolley Speed 40 fpm
Features Dual Speed Trolley VFD, Rubber Bumpers, Side Guide Rollers
Lifting Hook Material Carbon Steel
Includes Clutch Clutch Included
Overload Protection Included Yes
Brake Type DC Current
Chain Grade Grade 80
Maximum Lift Speed Not Applicable
Included Components Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Rubber Bumpers, Safety Latch Hook
Fixed Lift Speed 11 fpm
Clutch Type Friction Clutch
Minimum Lift Speed Not Applicable
Pendant IP Rating IP65
Chain Finish Nickel Plated
Controls Push Button Pendant=Mount Type=Motorized Trolley
Starts and Stops per Hour 120, 240
Duty Classification H4
Maximum Pulling Capacity Not Applicable
Number of Reeves 4
Motor Horsepower 4 3/4 hp
Headroom 46 1/2 in
Includes Brake Brake Included
For Outdoor Use Yes
Hoist IP Rating IP55
Lifting Hook Type Swivel Hook with Safety Latch
Maximum Lifting Capacity 20,000 lb
Current at Minimum Voltage 5.1 A
Trolley Wheel Material Steel
Current at Maximum Voltage 1.7 A
Body Finish Enamel
Number of Load Chains 1
Body Material Aluminum
Trolley IP Rating IP55
Programmable Non-Programmable
