NER-FG Food Grade Electric Chain Hoist 20' Lift-Capacity 2 Tons NER020L-FG Electric Chain Trolley HARRINGTON

Product Overview

Upgrade your food processing or packaging operations with the NER020L-FG-20 HARRINGTON NER-FG Food Grade Electric Chain Hoist. This high-quality hoist is designed specifically for food industry applications, ensuring the highest level of safety and efficiency.With a 20' lift capacity and Capacity ranging from 1/4 to 2 tons, this hoist provides the power and reliability you need to streamline your operations. Whether you need to transport heavy loads or lift equipment, this hoist will make the process effortless.One of the standout features of this hoist is its food-grade materials. It is made with materials that meet the strictest sanitation standards. This means you can rest assured that your food products will not be contaminated during the lifting process. Additionally, these materials allow for easy cleaning, saving you time and effort in maintaining a clean and hygienic workspace.The electric operation of this hoist ensures smooth and precise lifting. You can easily control the speed and direction of the lift, making it ideal for delicate food items that require gentle handling. The electric operation also eliminates the need for manual labor, reducing the risk of accidents and injuries.Investing in the NER020L-FG-20 HARRINGTON NER-FG Food Grade Electric Chain Hoist will provide you with a top-notch hoisting solution for your food processing needs. Its high-quality construction, food-grade materials, and electric operation make it a reliable and efficient tool for your business.Don't compromise on the safety and efficiency of your food processing operations. Choose the NER020L-FG-20 HARRINGTON NER-FG Food Grade Electric Chain Hoist and experience the benefits of a hoist designed specifically for the food industry. With its lifting capacity and food-grade materials, this hoist will help you streamline your operations and ensure the highest level of safety and hygiene.

Product Specifications

.

Part Number:

NER020L-FG-20

Color:

White

Hoist Lift:

20 ft

Product:

Electric Food Grade Chain Hoist, 4,000 lb, 20 ft, Hook Mounted-No Trolley, White=Hoist Mount=Hook Mounted-No Trolley

Includes:

Chain Container, Quick Disconnect Plugs On Pendant and Power Cord

Lift Speed:

14 fpm

Housing Width:

11 11/16 in

Manufacturers Warranty Length:

10 yr Brake Warranty, 3 yr

Housing Depth:

22 5/8 in

Housing Length:

27 7/8 in

For Minimum Beam Flange Width:

Not Applicable

For Maximum Beam Flange Width:

Not Applicable

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

11 11/16 in

Body Depth:

22 5/8 in

For Minimum Beam Height:

Not Applicable

Body Length:

27 7/8 in

Minimum Radius Curve:

Not Applicable

Maximum Lifting Length:

20 ft

Controller Cord Length:

16 ft

Trolley Wheel Diameter:

Not Applicable

Lifting Hook Opening Width:

22 5/8 in

Minimum Retracted Length:

22 19/32 in

Load Capacity:

4,000 lb

Minimum Between Hooks:

22 5/8 in

Motor HP:

2.4 hp

Phase:

3

Standards:

ASME B30.16, ASME HST-1M, FDA Approved, RoHS Compliant

Voltage:

230/460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Food Grade Oil

Reeving:

1

Thermal Protection:

Yes

Control Cord:

16 ft

Amps @ Low Volts:

2.4 A

Number of Speeds:

1

Trolley Configuration:

Hook Mounted

Trolley Speed:

Not Applicable

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

DC Current

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

14 fpm

Clutch Type:

Friction

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Epoxy Painted

Controls:

Push Button Pendant=Mount Type=Hook Mounted-No Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

2 3/8 hp

Headroom:

22 5/8 in

Includes Brake:

Brake Included

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

4,000 lb

Current at Minimum Voltage:

2.4 A

Trolley Wheel Material:

Not Applicable

Current at Maximum Voltage:

2.4 A

Body Finish:

Epoxy Painted

Number of Load Chains:

1

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
