NER-FG Food Grade Electric Chain Hoist 20' Lift-Capacity 1 Tons NER010L-FG Electric Chain Trolley HARRINGTON

Product Overview

The NER010L-FG-20 HARRINGTON NER-FG Food Grade Electric Chain Hoist is an essential tool for food processing and packaging industries, delivering unmatched performance and reliability in environments that demand the highest standards of cleanliness and safety. Designed specifically for food-grade applications, this electric chain hoist boasts a robust lift capacity of 1 ton and a generous 20-foot lifting height, making it highly adaptable to a variety of tasks within the food sector.

Engineered with precision, the NER010L-FG-20 is built to handle heavy loads seamlessly, significantly enhancing productivity and operational efficiency. The advanced lifting mechanism provides smooth, precise control, allowing operators to raise and lower products effortlessly, thus ensuring consistent quality in your food processing operations. This innovative design not only minimizes manual labor but also streamlines workflows, making it easier to handle bulk ingredients and packaged goods.

Durability is at the forefront of the NER-FG‚ design, ensuring it can withstand the rigorous demands of food processing environments. Its construction meets stringent hygiene standards, promoting a sanitary working environment and providing peace of mind in compliance with industry regulations.

By incorporating the NER010L-FG-20 hoist into your operations, you are investing in the future of your production capabilities. This state-of-the-art equipment optimizes your workflow, leading to increased output and profitability while maintaining the highest levels of safety and efficiency. Elevate your food processing or packaging operations with confidence and experience the transformative benefits of the NER010L-FG-20 HARRINGTON NER-FG Food Grade Electric Chain Hoist, where quality and functionality come together to enhance your business success.

Product Specifications

.

Part Number:

NER010L-FG-20

Color:

White

Hoist Lift:

20 ft

Product:

Electric Food Grade Chain Hoist, 2,000 lb, 20 ft, Hook Mounted-No Trolley, White=Hoist Mount=Hook Mounted-No Trolley

Includes:

Chain Container, Quick Disconnect Plugs On Pendant and Power Cord

Lift Speed:

14 fpm

Housing Width:

9 11/16 in

Manufacturers Warranty Length:

10 yr Brake Warranty, 3 yr

Housing Depth:

17 in

Housing Length:

24 1/8 in

For Minimum Beam Flange Width:

Not Applicable

For Maximum Beam Flange Width:

Not Applicable

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

9 11/16 in

Body Depth:

17 in

For Minimum Beam Height:

Not Applicable

Body Length:

24 1/8 in

Minimum Radius Curve:

Not Applicable

Maximum Lifting Length:

20 ft

Controller Cord Length:

16 ft

Trolley Wheel Diameter:

Not Applicable

Lifting Hook Opening Width:

17 in

Minimum Retracted Length:

16 29/32 in

Load Capacity:

2,000 lb

Minimum Between Hooks:

17 in

Motor HP:

1.2 hp

Phase:

3

Standards:

ASME B30.16, ASME HST-1M, FDA Approved, RoHS Compliant

Voltage:

230/460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Food Grade Oil

Clutch:

Friction

Item:

Electric Food Grade Chain Hoist

Reeving:

1

Thermal Protection:

Yes

Classification:

H4

Control Cord:

16 ft

Amps @ Low Volts:

4.8 A

Number of Speeds:

1

Trolley Configuration:

Hook Mounted-No Trolley

Trolley Speed:

Not Applicable

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

DC Current

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

14 fpm

Clutch Type:

Friction

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Epoxy Painted

Controls:

Push Button Pendant=Mount Type=Hook Mounted-No Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

1 1/4 hp

Headroom:

17 in

Includes Brake:

Brake Included

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

2,000 lb

Current at Minimum Voltage:

4.8 A

Trolley Wheel Material:

Not Applicable

Current at Maximum Voltage:

4.8 A

Body Finish:

Epoxy Painted

Number of Load Chains:

1

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
