NER Electric Chain Hoist 15' Lift-Capacity 1/2 Tons NER005S Electric Chain Hoist HARRINGTON

Product Overview

The NER005S-15 HARRINGTON NER Electric Chain Hoist 15' Lift is the ultimate solution for your heavy lifting needs. With Capacity ranging from 1/8 to 20 tons, this electric hoist is designed to handle the toughest conditions and deliver outstanding performance.Experience the power and efficiency of the NER005S Electric Chain Hoist. Engineered with advanced features and exceptional build quality, this hoist ensures reliability and durability in every operation. Whether you need to lift heavy loads in a construction site or industrial setting, this hoisting equipment is built to excel.Harrington's reputation for top-notch quality and unmatched performance speaks for itself. By investing in the NER005S-15 HARRINGTON NER Electric Chain Hoist 15' Lift, you are choosing a product that will elevate your productivity and help you achieve outstanding results. Say goodbye to delays and inefficiencies, and say hello to increased efficiency and performance.Featuring a 15' lift capacity, this electric chain hoist provides you with the flexibility and convenience you need to tackle any lifting task. Its sturdy build and robust construction make it capable of handling heavy loads consistently and safely. With the NER005S-15 HARRINGTON NER Electric Chain Hoist, you can trust that your lifting operations will be smooth and seamless.Don't settle for less when it comes to your hoisting equipment. Choose the NER005S-15 HARRINGTON NER Electric Chain Hoist 15' Lift and experience the difference. Take your operations to new heights and rely on this powerful hoist to get the job done efficiently and safely.Invest in quality, invest in performance, invest in the NER005S-15 HARRINGTON NER Electric Chain Hoist 15' Lift today. Start experiencing the benefits of superior performance and reliability in your lifting operations. Get ready to take on any challenge with confidence and efficiency.

Product Specifications

.

Part Number:

NER005S-15

Color:

Yellow

Hoist Lift:

15 ft

Product:

Electric Chain Hoist, 1,000 lb, 15 ft, Hook Mounted-No Trolley, Yellow=Hoist Mount=Hook Mounted-No Trolley

Includes:

Chain Container, Limit Switches, Plug-In Connections

Lift Speed:

29 fpm

Housing Width:

13 11/16 in

Manufacturers Warranty Length:

10 yr Brake Warranty, 3 yr

Housing Depth:

7 1/2 in

Housing Length:

20 3/32 in

For Minimum Beam Flange Width:

Not Applicable

For Maximum Beam Flange Width:

Not Applicable

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

13 11/16 in

Body Depth:

7 1/2 in

For Minimum Beam Height:

Not Applicable

Body Length:

20 3/32 in

Minimum Radius Curve:

Not Applicable

Maximum Lifting Length:

15 ft

Controller Cord Length:

8 3/16 ft

Trolley Wheel Diameter:

Not Applicable

Lifting Hook Opening Width:

1 3/32 in

Minimum Retracted Length:

14 19/32 in

Load Capacity:

1,000 lb

Minimum Between Hooks:

14 5/8 in

Motor HP:

1.2 hp

Phase:

3

Standards:

ANSI/ASME B30.16, ANSI/ASME HST-1M, ANSI/NFPA 70, UL 1340

Voltage:

208/230/460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

1

Thermal Protection:

Yes

Brake:

DC Current

Control Cord:

11 ft

Finish:

Electrostatic Enamel

Amps @ Low Volts:

4.8 A

Number of Speeds:

1

Trolley Configuration:

Hook Mounted-No Trolley

Trolley Speed:

Not Applicable

Features:

Count Hour Meter, Dual Speed VFD, Easy Access Suspension, Extreme Duty Motor, Secondary Brake, Smart Brake Technology, State-Of-The-Art Chain Technology, Unique Smart Limit Option

Material:

Die Cast Aluminum

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

DC Current

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

29 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Hook Mounted-No Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

1 1/4 hp

Headroom:

14 19/32 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

1,000 lb

Current at Minimum Voltage:

4.8 A

Trolley Wheel Material:

Not Applicable

Current at Maximum Voltage:

2.5 A

Body Finish:

Painted

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
