NER-FG Food Grade Electric Chain Hoist 10' Lift-Capacity 1/2 Tons NER005L-FG Electric Chain Trolley HARRINGTON

Product Overview

The NER005L-FG-10 HARRINGTON NER-FG Food Grade Electric Chain Hoist is the perfect solution for food processing and packaging applications. Designed with the highest industry standards in mind, this electric hoist guarantees optimal performance and efficiency, ensuring the safety and integrity of your food products. With a lift capacity range of 1/2 Tons, this hoist can handle a wide variety of loads, making it versatile for any food processing operation. Whether you need to lift heavy containers, equipment, or ingredients, the NER005L-FG hoist has you covered. One of the standout features of this hoist is its focus on food safety and hygiene. The NER005L-FG hoist is specifically designed to meet the strictest standards in the food industry, giving you peace of mind and confidence in the quality and integrity of your products. Say goodbye to concerns about contamination or cross-contamination, as this hoist meets all necessary regulations and guidelines. In addition to its food-grade construction, the NER005L-FG hoist also offers exceptional performance and durability. Its state-of-the-art design incorporates innovative features that enhance its efficiency and reliability. With a 10-foot lift capacity, this hoist is capable of handling even the most demanding food processing tasks with ease. Investing in the NER005L-FG-10 HARRINGTON NER-FG Food Grade Electric Chain Hoist means investing in long-term success for your food processing operations. Its exceptional quality, performance, and focus on food safety will help you take your business to a whole new level. Upgrade your food processing and packaging operations today with the NER005L-FG-10 HARRINGTON NER-FG Food Grade Electric Chain Hoist. Experience superior performance, peace of mind, and industry-leading efficiency in all your lifting and handling tasks. Trust in the reliability of this hoist to meet your food safety and hygiene requirements, and elevate your business to new heights.

Product Specifications

.

Part Number:

NER005L-FG-10

Color:

White

Hoist Lift:

10 ft

Product:

Electric Food Grade Chain Hoist, 1,000 lb, 10 ft, Hook Mounted-No Trolley, White=Hoist Mount=Hook Mounted-No Trolley

Includes:

Chain Container, Quick Disconnect Plugs On Pendant and Power Cord

Lift Speed:

15 fpm

Housing Width:

8 1/2 in

Manufacturers Warranty Length:

10 yr Brake Warranty, 3 yr

Housing Depth:

14 5/8 in

Housing Length:

22 3/8 in

For Minimum Beam Flange Width:

Not Applicable

For Maximum Beam Flange Width:

Not Applicable

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

8 1/2 in

Body Depth:

14 5/8 in

For Minimum Beam Height:

Not Applicable

Body Length:

22 3/8 in

Minimum Radius Curve:

Not Applicable

Maximum Lifting Length:

10 ft

Controller Cord Length:

6 ft

Trolley Wheel Diameter:

Not Applicable

Lifting Hook Opening Width:

14 5/8 in

Minimum Retracted Length:

14 19/32 in

Load Capacity:

1,000 lb

Minimum Between Hooks:

14 5/8 in

Motor HP:

0.75 hp

Phase:

3

Standards:

ASME B30.16, ASME HST-1M, FDA Approved, RoHS Compliant

Voltage:

208/230/460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Food Grade Oil

Reeving:

1

Thermal Protection:

Yes

Control Cord:

6 ft

Amps @ Low Volts:

3.4 A

Number of Speeds:

1

Trolley Configuration:

Hook Mounted-No Trolley

Trolley Speed:

Not Applicable

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

DC Current

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

15 fpm

Clutch Type:

Friction

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Epoxy Painted

Controls:

Push Button Pendant=Mount Type=Hook Mounted-No Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

3/4 hp

Headroom:

14 5/8 in

Includes Brake:

Brake Included

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

1,000 lb

Current at Minimum Voltage:

3.4 A

Trolley Wheel Material:

Not Applicable

Current at Maximum Voltage:

3.4 A

Body Finish:

Epoxy Painted

Number of Load Chains:

1

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
