NER Electric Chain Hoist 20' Lift-Capacity 1/2 Tons NER005L Electric Chain Hoist HARRINGTON

Product Overview

The NER005L-20 HARRINGTON NER Electric Chain Hoist is a game-changer in the world of lifting equipment. With its exceptional durability and reliability, this electric hoist is designed to handle even the most challenging conditions. Whether you're working in a demanding industrial setting or tackling tough construction projects, this hoist will not disappoint.Featuring a 20-foot lift capacity, the NER005L-20 offers a generous amount of space for heavy loads to be lifted with ease. Its wide range of load Capacity, 1/2 Tons, ensures that no job is too big or small for this powerful hoist.Crafted with precision and attention to detail, the NER005L-20 is built to withstand the harshest working environments. Its robust construction guarantees that it can handle heavy loads without compromising on performance. With this hoist in your arsenal, you can have peace of mind knowing that your equipment can handle any challenge thrown at it.Investing in the NER005L-20 means investing in peak performance. This hoist will allow you to effortlessly lift heavy loads, increasing productivity and efficiency on the job site. Its reliability and durability ensure that it will serve you for years to come.In addition to its impressive capabilities, the NER005L-20 also boasts user-friendly features that make operation a breeze. Its intuitive controls allow for precise movements, while its compact and portable design makes it easy to transport and set up. Whether you're a seasoned professional or a beginner, this hoist's user-friendly interface will have you up and running in no time.Don't settle for subpar lifting equipment. Choose the NER005L-20 HARRINGTON NER Electric Chain Hoist and experience unrivaled performance like never before. Invest in quality, invest in peak performance, and get the job done right with this exceptional hoist.

Product Specifications

.

Part Number:

NER005L-20

Color:

Yellow

Hoist Lift:

20 ft

Product:

Electric Chain Hoist, 1,000 lb, 20 ft, Hook Mounted-No Trolley, Yellow=Hoist Mount=Hook Mounted-No Trolley

Includes:

Chain Container, Limit Switches, Plug-In Connections

Lift Speed:

15 fpm

Housing Width:

13 11/16 in

Manufacturers Warranty Length:

10 yr Brake Warranty, 3 yr

Housing Depth:

7 1/2 in

Housing Length:

20 3/16 in

For Minimum Beam Flange Width:

Not Applicable

For Maximum Beam Flange Width:

Not Applicable

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

13 11/16 in

Body Depth:

7 1/2 in

For Minimum Beam Height:

Not Applicable

Body Length:

20 3/16 in

Minimum Radius Curve:

Not Applicable

Maximum Lifting Length:

20 ft

Controller Cord Length:

8 3/16 ft

Trolley Wheel Diameter:

Not Applicable

Lifting Hook Opening Width:

1 3/32 in

Minimum Retracted Length:

14 19/32 in

Load Capacity:

1,000 lb

Minimum Between Hooks:

14 5/8 in

Motor HP:

0.75 hp

Phase:

3

Standards:

ANSI/ASME B30.16, ANSI/ASME HST-1M, ANSI/NFPA 70, UL 1340

Voltage:

208/230/460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

1

Thermal Protection:

Yes

Control Cord:

16 ft

Amps @ Low Volts:

3.4 A

Number of Speeds:

1

Trolley Configuration:

Hook Mounted-No Trolley

Trolley Speed:

Not Applicable

Features:

Count Hour Meter, Dual Speed VFD, Easy Access Suspension, Extreme Duty Motor, Secondary Brake, Smart Brake Technology, State-Of-The-Art Chain Technology, Unique Smart Limit Option

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

DC Current

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

15 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Hook Mounted-No Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

3/4 hp

Headroom:

14 19/32 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

1,000 lb

Current at Minimum Voltage:

3.4 A

Trolley Wheel Material:

Not Applicable

Current at Maximum Voltage:

1.7 A

Body Finish:

Painted

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
