NER Electric Chain Hoist 15' Lift-Capacity 1/2 Tons NER005L Electric Chain Hoist HARRINGTON

Product Overview

The NER005L-15 HARRINGTON NER Electric Chain Hoist 15' Lift is a powerful and reliable tool designed to handle the toughest lifting jobs. This electric hoist has superior engineering and rugged construction, allowing it to withstand harsh conditions and deliver reliable performance every time.With a capacity 1/2 Tons, the NER005L-15 HARRINGTON Electric Chain Hoist can effortlessly handle heavy loads. Whether you're lifting equipment, materials, or machinery, this hoist has the power and strength to get the job done with ease.The 15' lift provides ample reach, making it an ideal choice for various applications, such as warehouses, construction sites, and manufacturing facilities. You can easily lift and transport items to higher heights with this hoist.Equipped with the latest technology and features, this electric chain hoist offers unmatched power and precision. Its ergonomic design ensures comfortable and easy operation, reducing operator fatigue and improving productivity. The advanced safety features protect both the operator and the load, giving you peace of mind and confidence in its performance.Furthermore, the NER005L-15 HARRINGTON Electric Chain Hoist is designed for maximum durability and longevity. Its robust construction and high-quality materials ensure that it can withstand heavy-duty use and provide years of dependable service.Upgrade your lifting capabilities with the NER005L-15 HARRINGTON NER Electric Chain Hoist. Whether you need to lift heavy machinery, transport materials, or perform maintenance tasks, this electric hoist will revolutionize your lifting game. It delivers unmatched power, precision, and reliability, making it the best investment for your lifting needs. Experience the difference today by investing in the NER005L-15 HARRINGTON NER Electric Chain Hoist 15' Lift.

Product Specifications

.

Part Number:

NER005L-15

Color:

Yellow

Hoist Lift:

15 ft

Product:

Electric Chain Hoist, 1,000 lb, 15 ft, Hook Mounted-No Trolley, Yellow=Hoist Mount=Hook Mounted-No Trolley

Includes:

Chain Container, Limit Switches, Plug-In Connections

Lift Speed:

15 fpm

Housing Width:

13 11/16 in

Manufacturers Warranty Length:

10 yr Brake Warranty, 3 yr

Housing Depth:

7 1/2 in

Housing Length:

20 3/16 in

For Minimum Beam Flange Width:

Not Applicable

For Maximum Beam Flange Width:

Not Applicable

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

13 11/16 in

Body Depth:

7 1/2 in

For Minimum Beam Height:

Not Applicable

Body Length:

20 3/16 in

Minimum Radius Curve:

Not Applicable

Maximum Lifting Length:

15 ft

Controller Cord Length:

8 3/16 ft

Trolley Wheel Diameter:

Not Applicable

Lifting Hook Opening Width:

1 3/32 in

Minimum Retracted Length:

14 19/32 in

Load Capacity:

1,000 lb

Minimum Between Hooks:

14 5/8 in

Motor HP:

0.75 hp

Phase:

3

Standards:

ANSI/ASME B30.16, ANSI/ASME HST-1M, ANSI/NFPA 70, UL 1340

Voltage:

208/230/460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

1

Thermal Protection:

Yes

Control Cord:

11 ft

Finish:

Electrostatic Enamel

Amps @ Low Volts:

3.4 A

Number of Speeds:

1

Trolley Configuration:

Hook Mounted-No Trolley

Trolley Speed:

Not Applicable

Features:

Count Hour Meter, Dual Speed VFD, Easy Access Suspension, Extreme Duty Motor, Secondary Brake, Smart Brake Technology, State-Of-The-Art Chain Technology, Unique Smart Limit Option

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

DC Current

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

15 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Programmable by Internal Controls=Mount Type=Hook Mounted-No Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

3/4 hp

Headroom:

14 19/32 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

1,000 lb

Current at Minimum Voltage:

3.4 A

Trolley Wheel Material:

Not Applicable

Current at Maximum Voltage:

1.7 A

Body Finish:

Painted

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
