EQ Electric Chain Hoist 10' Lift-Capacity 1/8 Ton EQ001SD Electric Chain Hoist HARRINGTON

Product Overview

The EQ001SD-10 HARRINGTON EQ Electric Chain Hoist revolutionizes your industrial operations, providing exceptional lifting solutions that enhance workflow efficiency across various applications. This powerful hoist is engineered to manage medium to heavy-duty tasks with ease, boasting a reliable lift capacity of 1/8 ton.

Designed for both industrial environments and workstation applications, the EQ001SD-10 features a compact design for easy integration into tight spaces. Its robust construction ensures smooth operation, allowing you to tackle challenging lifting tasks while maintaining high efficiency and productivity levels. The hoist is equipped with advanced technological features that facilitate precise control over your lifting movements, enabling optimal performance in various settings.

• Powerful Lift Capacity: Handles up to 1/8 ton with confidence, ideal for transporting machinery, tools, and materials.
• 10-Foot Lift Height: Modifies your working range effectively, ensuring flexibility in maneuvering heavy loads.
• Variable Frequency Drive: Promotes energy efficiency and offers exceptional control over lifting speed and movements.
• Dual Speed Control: Provides versatility in operations with high and low-speed settings to suit different lifting requirements.
• Compact Design: Facilitates installation in confined spaces without sacrificing strength or capability.
• Durability: Built with high-quality materials to withstand demanding industrial applications.
• Harrington Reliability: Trusted brand known for its commitment to quality and excellence in hoisting solutions.

The EQ001SD-10 HARRINGTON EQ Electric Chain Hoist stands out in its class, providing an optimal combination of power, precision, and portability. Elevate your occupational safety and productivity by implementing this hoist into your workspace. Make an intelligent investment in a trusted tool that not only meets but exceeds your lifting requirements, paving the way for a more efficient and effective operation.

Product Specifications

.

Part Number:

EQ001SD-10

Color:

Yellow

Hoist Lift:

10 ft

Product:

Electric Chain Hoist, 250 lb, 10 ft, Hook Mounted-No Trolley, Yellow=Hoist Mount=Hook Mounted-No Trolley

Includes:

Chain Container

Lift Speed:

56/9.3 fpm

Housing Width:

14 13/32 in

Manufacturers Warranty Length:

3 yr

Housing Depth:

9 7/64 in

Housing Length:

17 19/64 in

For Minimum Beam Flange Width:

Not Applicable

For Maximum Beam Flange Width:

Not Applicable

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

3 yr

Body Width:

14 13/32 in

Body Depth:

9 1/8 in

For Minimum Beam Height:

15 in

Body Length:

17 5/16 in

Minimum Radius Curve:

10 in

Maximum Lifting Length:

10 ft

Controller Cord Length:

6 ft

Trolley Wheel Diameter:

Not Applicable

Lifting Hook Opening Width:

1 3/32 in

Minimum Retracted Length:

17 5/16 in

Load Capacity:

250 lb

Minimum Between Hooks:

17 5/16 in

Motor HP:

0.67 hp

Phase:

3

Standards:

ASME HST-4, C22.2 No.33/14-13/66, CSA, UL 508A

Voltage:

460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

1

Thermal Protection:

Yes

Control Cord:

6 ft

Amps @ Low Volts:

2.9 A

Number of Speeds:

2

Trolley Configuration:

Hook/Suspension Bar Mounted

Trolley Speed:

Not Applicable

Features:

Extreme-Duty, Fan-Cooled Motor, No-Load High Speed, Self-Adjusting Maintenance-Free Brake, Unique Chain Guide, Variable Frequency Drive (VFD)

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

Pull Rotor

Chain Grade:

Grade 80

Maximum Lift Speed:

56 fpm

Included Components:

Chain Container, Pendant, Safety Latch Hook

Fixed Lift Speed:

Not Applicable

Clutch Type:

Friction

Minimum Lift Speed:

9.3 fpm

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Hook Mounted-No Trolley

Starts and Stops per Hour:

120, 240

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

5/8 hp

Headroom:

17 5/16 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

250 lb

Current at Minimum Voltage:

5.1 A

Trolley Wheel Material:

Not Applicable

Current at Maximum Voltage:

2.8 A

Body Finish:

Epoxy Painted

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Programmable by Internal Controls
