CF Hand Chain Hoist 20' Lift-Capacity 1 1/2 Tons CF015 Hand Chain Hoist HARRINGTON

Product Overview

Experience the superior performance and durability of the CF015-20 HARRINGTON CF Hand Chain Hoist. This top-of-the-line hoist is designed to simplify and enhance your lifting tasks.The CF015-20 is constructed with a robust yet lightweight die-cast aluminum body, ensuring both strength and ease of use. Its high-strength heat-treated gear guarantees dependable performance, while the pre-lubricated ball bearings enable smooth and effortless lifting.With its precision machined gears and Weston-style load brake, this hoist operates with exceptional accuracy and control. You can trust it to provide consistent results, allowing you to handle heavy loads effortlessly and with confidence.Featuring a generous 20' lift capacity, this hoist is suitable for a wide range of lifting needs. Whether you are working with small or large objects, the CF015-20 has got you covered. It is available in Capacity ranging from 1 1/2 Tons, offering options to meet your specific requirements.Say goodbye to the inconvenience and strain of manual hoists. The CF Hand Chain Hoist offers a simple and efficient solution to your lifting challenges. It eliminates the need for manual labor, allowing you to effortlessly lift heavy objects.Not only does this hoist deliver exceptional performance, but it also requires minimal maintenance. Its durable construction and high-quality materials ensure a long service life and low upkeep. You can rely on this hoist to provide consistent results for years to come.Whether you are a professional in the construction industry or a DIY enthusiast, the CF015-20 HARRINGTON CF Hand Chain Hoist is an invaluable tool that will simplify and enhance your lifting tasks, making them safer and easier. So why struggle with manual hoists when you can experience the simplicity and unmatched performance of this outstanding hoist? Invest in the CF015-20 HARRINGTON CF Hand Chain Hoist today and feel the difference it can make.

Product Specifications

.

Part Number:

CF015-20

Color:

Yellow

Hoist Lift:

20 ft

Product:

Manual Chain Hoist, 3000 lb., Lift 20 ft.=Hoist Mount=Hook Mounted-No Trolley

Housing Width:

8 in

Manufacturers Warranty Length:

2 yr

Housing Depth:

6 in

Housing Length:

17 5/16 in

For Minimum Beam Flange Width:

Not Applicable

For Minimum Beam Flange Height:

Not Applicable

For Maximum Beam Flange Width:

Not Applicable

For Maximum Beam Flange Height:

Not Applicable

Body Width:

8 in

Body Depth:

6 in

Body Material:

Die-Cast Aluminum

Maximum Lifting Length:

20 ft

Lifting Hook Opening Width:

1 5/16 in

Minimum Retracted Length:

17 5/16 in

Load Capacity:

3,000 lb

Minimum Between Hooks:

17 1/4 in

Standards:

ANSI/ASME B30.16, ANSI/ASME HST-2M

Item:

Manual Chain Hoist

Brake:

Weston Style

Trolley Configuration:

Hook Mounted-No Trolley

Features:

Heat-Treated Main Pinion Shaft, Lightweight Die-Cast Aluminum Housing, Reliable Weston-Style Load Brake, Smooth Running Pre-Lubricated Bearings

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Not Included

Overload Protection Included:

No

Chain Grade:

Grade 100

Included Components:

Safety Latch Hooks

Chain Finish:

Nickel Plated

Controls:

=Mount Type=Hook Mounted-No Trolley

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Headroom:

17 5/16 in

Includes Brake:

Brake Included

Lifting Hook Type:

Hook with Safety Latch

Maximum Lifting Capacity:

3,000 lb

Number of Load Chains:

1
