CB Hand Chain Hoist Lift-Capacity 20 Ton CB200 Hand Chain Hoist HARRINGTON

Write a Review
$13,653.34
$12,458.67
(You save $1,194.67 )
SKU: CB200-10-15-1
Condition: New
Weight: 657.00 LBS
Width: 34.50 (in)
Height: 36.00 (in)
Depth: 26.00 (in)
Shipping: Free Shipping
Color: Yellow
Hoist Lift: 10 ft
Manufacturers Warranty Length: 2 yr
For Minimum Beam Flange Width: Not Applicable
For Minimum Beam Flange Height: Not Applicable
For Maximum Beam Flange Width: Not Applicable
For Maximum Beam Flange Height: Not Applicable
Body Width: 29 13/32 in
Body Depth: 14 11/16 in
Body Material: Steel
Maximum Lifting Length: 10 ft
Lifting Hook Opening Width: 3 3/16 in
Minimum Retracted Length: 46 1/2 in
Load Capacity: 40,000 lb
Minimum Between Hooks: 46 1/2 in
Standards: ANSI/ASME B30.16, ANSI/ASME HST-2M
Item: Manual Chain Hoist
Brake: Weston Style
Trolley Configuration: Hook Mounted-No Trolley
Features: Bearing-Supported High-Strength Pinion, Double Pawl Springs, High Impact Steel Housing, Maintenance-Free Slip Clutch
Lifting Hook Material: Carbon Steel
Includes Clutch: Clutch Included
Overload Protection Included: Yes
Chain Grade: Grade 100
Included Components: Safety Latch Hooks
Controls: =Mount Type=Hook Mounted-No Trolley
Maximum Pulling Capacity: Not Applicable
Number of Reeves: 8
Headroom: 46 1/2 in
Includes Brake: Brake Included
Lifting Hook Type: Hook with Safety Latch
Maximum Lifting Capacity: 40,000 lb
Number of Load Chains: 1
Adding to cart… The item has been added
CB Hand Chain Hoist Lift-Capacity 20 Ton CB200 Hand Chain Hoist HARRINGTON

CB Hand Chain Hoist Lift-Capacity 20 Ton CB200 Hand Chain Hoist HARRINGTON

$13,653.34
$12,458.67
(You save $1,194.67 )

CB Hand Chain Hoist Lift-Capacity 20 Ton CB200 Hand Chain Hoist HARRINGTON

$13,653.34
$12,458.67
(You save $1,194.67 )

Experience unparalleled durability and reliability with the CB200 HARRINGTON CB Hand Chain Hoist. This heavy-duty industrial hoist is built to withstand the toughest conditions and deliver unmatched performance. With its Capacity ranging from 20 ton, this hoist is a powerhouse that can handle any heavy load with ease.The CB200 HARRINGTON CB Hand Chain Hoist is engineered for effortless lifting. Its sturdy chain and hooks ensure a secure attachment, giving you the confidence to move your materials without any concerns. Equipped with a mechanical brake system, this hoist provides precise control and allows for smooth and controlled lowering of your load. The anti-drop latch design adds an extra layer of safety, preventing accidental release during operation.Designed for operator convenience, this hoist features a compact and lightweight design that makes it easy to transport and maneuver in tight spaces. The ergonomically designed hand chain ensures comfortable operation, reducing operator fatigue and increasing productivity.Maintenance and repair are a breeze with the CB200 HARRINGTON CB Hand Chain Hoist. Its simple and straightforward design allows for quick inspections and lubrication. If any components need replacement, this hoist is designed to be easily repairable, saving you time and money in the long run.Invest in the CB200 HARRINGTON CB Hand Chain Hoist and elevate your industrial operations to new heights. Its unbeatable durability, unmatched reliability, and easy maintenance make it an essential tool for any heavy-duty lifting application. Whether you are working in construction, manufacturing, or any other demanding industry, trust the CB200 HARRINGTON CB Hand Chain Hoist to get the job done safely and efficiently.

Buyer must notify HHI in writing within sixty (60) days of discovery of any alleged defect, if within the applicable warranty period. All products sold by HHI are warranted to be free from defects in material and workmanship from date of shipment by HHI for the following periods: 1 year – Electric and Air Powered Hoists (excluding (N)ER2 Hoists and EQ/SEQ Hoists), Powered Trolleys, Powered Tiger Track Jibs and Gantries, Crane Components, Below the Hook Devices, Spare / Replacement Parts 2 years – Manual Hoists & Trolleys, Beam Clamps 3 years – (N)ER2 Hoists, EQ/SEQ Hoists, (T)EM/(T)SEM hoists, and RY Hoists 5 years – Manual Tiger Track Jibs and Gantries, Hoist Motor Brakes for EQ/SEQ, (T)EM/(T)SEM, and RY 10 years – (N)ER2 Brake, TNER Hoist Motor Brake The product must be used in accordance with manufacturer’s recommendations and must not have been subject to abuse, lack of maintenance, misuse, negligence, or unauthorized repairs or alterations. Should any defect in material or workmanship occur during the above time period in any product, as determined by HHI’s inspection of the product, HHI agrees, at its discretion, either to replace (not including installation) or repair the part or product free of charge. For customers in the U.S., delivery shall be made F.O.B. HHI’s place of business. For international customers, delivery shall be made FCA HHI place of business, United States of America (Incoterms 2010). No warranty claim will be honored without a valid proof of purchase. Customer must obtain a Return Goods Authorization as directed by HHI or its published repair center prior to shipping product for warranty evaluation. An explanation of the complaint must accompany the product. Product must be returned freight prepaid. Upon repair, the product will be covered for the remainder of the original warranty period. Replacement parts installed after the original warranty period will only be eligible for replacement (not including installation) for a period of one year from the installation date. If it is determined there is no defect, or that the defect resulted from causes not within the scope of HHI’s warranty, the customer will be responsible for the costs of returning the product. HHI DISCLAIMS ANY AND ALL OTHER WARRANTIES OF ANY KIND, EXPRESSED OR IMPLIED, AS TO THE PRODUCT’S MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. HHI WILL NOT BE LIABLE FOR DEATH, INJURIES TO PERSONS OR PROPERTY OR FOR INCIDENTAL, CONTINGENT, SPECIAL OR CONSEQUENTIAL DAMAGES, LOSS OR EXPENSE ARISING IN CONNECTION WITH THE USE OR MISUSE OF THE PRODUCTS, REGARDLESS OF WHETHER THE DAMAGE, LOSS OR EXPENSE RESULTS FROM ANY ACT OR FAILURE TO ACT BY HHI, WHETHER NEGLIGENT OR WILLFUL, OR FROM ANY OTHER CAUSE.
