CB Hand Chain Hoist Lift-Capacity 1 1/2 Ton CB015 Hand Chain Hoist HARRINGTON

Write a Review
$1,779.28
$1,623.59
$1,424.97
(You save $354.31 )
SKU: CB015 - 10
Condition: New
Availability: In stock
Weight: 32.00 LBS
Width: 10.25 (in)
Height: 9.00 (in)
Depth: 13.25 (in)
Shipping: Free Shipping
Part Number: CB015-10
Color: Yellow
Hoist Lift: 10 ft
Includes: 8-1/2 ft Hand Chain
Housing Width: 7 1/4 in
Manufacturers Warranty Length: 2 yr
Housing Depth: 6 3/4 in
Housing Length: 13 13/16 in
For Minimum Beam Flange Width: Not Applicable
For Minimum Beam Flange Height: Not Applicable
For Maximum Beam Flange Width: Not Applicable
For Maximum Beam Flange Height: Not Applicable
Body Width: 7 3/16 in
Body Depth: 6 11/16 in
Body Material: Steel
Maximum Lifting Length: 10 ft
Lifting Hook Opening Width: 1 5/16 in
Minimum Retracted Length: 13 13/16 in
Load Capacity: 3,000 lb
Minimum Between Hooks: 14 in
Standards: ANSI/ASME B30.16, ANSI/ASME HST-2M
Item: Manual Chain Hoist
Brake: Weston Style
Trolley Configuration: Hook Mounted-No Trolley
Features: Bearing-Supported High-Strength Pinion, Double Pawl Springs, High Impact Steel Housing, Maintenance-Free Slip Clutch
Lifting Hook Material: Carbon Steel
Includes Clutch: Clutch Included
Overload Protection Included: Yes
Chain Grade: Grade 100
Included Components: Safety Latch Hooks
Controls: =Mount Type=Hook Mounted-No Trolley
Maximum Pulling Capacity: Not Applicable
Number of Reeves: 1
Headroom: 13 13/16 in
Includes Brake: Brake Included
Lifting Hook Type: Hook with Safety Latch
Maximum Lifting Capacity: 3,000 lb
Number of Load Chains: 1
Adding to cart… The item has been added
CB Hand Chain Hoist Lift-Capacity 1 1/2 Ton CB015 Hand Chain Hoist HARRINGTON

CB Hand Chain Hoist Lift-Capacity 1 1/2 Ton CB015 Hand Chain Hoist HARRINGTON

$1,779.28
$1,623.59
$1,424.97
(You save $354.31 )

CB Hand Chain Hoist Lift-Capacity 1 1/2 Ton CB015 Hand Chain Hoist HARRINGTON

$1,779.28
$1,623.59
$1,424.97
(You save $354.31 )

Experience the power and reliability of the CB015 HARRINGTON CB Hand Chain Hoist. This heavy-duty hoist is the perfect solution for all your industrial lifting needs. Its robust construction and high-quality internal components ensure top performance and durability, allowing for consistent use in demanding environments.With easy maintenance and repairability, the CB015 HARRINGTON CB Hand Chain Hoist is built to last. You can rely on this hoist for reliable and efficient lifting operations, giving you peace of mind and allowing you to focus on your work. Choose from a variety of Capacity ranging from 1 1/2 ton. No matter the job, this hoist can handle it. From heavy machinery to large objects, the CB015 HARRINGTON CB Hand Chain Hoist has got you covered. Its high lifting capacity and sturdy design make it ideal for even the toughest jobs.The CB015 HARRINGTON CB Hand Chain Hoist is designed with precision and attention to detail. Its smooth and easy-to-operate chain mechanism ensures precise control and smooth lifting. The ergonomically designed hand chain provides comfortable operation, reducing strain and fatigue during prolonged use.Upgrade your industrial products with the CB015 HARRINGTON CB Hand Chain Hoist. Its exceptional reliability, high-quality construction, and user-friendly design make it the perfect choice for any industrial setting. Invest in this hoist today and experience the difference in performance and reliability.

Buyer must notify HHI in writing within sixty (60) days of discovery of any alleged defect, if within the applicable warranty period. All products sold by HHI are warranted to be free from defects in material and workmanship from date of shipment by HHI for the following periods: 1 year – Electric and Air Powered Hoists (excluding (N)ER2 Hoists and EQ/SEQ Hoists), Powered Trolleys, Powered Tiger Track Jibs and Gantries, Crane Components, Below the Hook Devices, Spare / Replacement Parts 2 years – Manual Hoists & Trolleys, Beam Clamps 3 years – (N)ER2 Hoists, EQ/SEQ Hoists, (T)EM/(T)SEM hoists, and RY Hoists 5 years – Manual Tiger Track Jibs and Gantries, Hoist Motor Brakes for EQ/SEQ, (T)EM/(T)SEM, and RY 10 years – (N)ER2 Brake, TNER Hoist Motor Brake The product must be used in accordance with manufacturer’s recommendations and must not have been subject to abuse, lack of maintenance, misuse, negligence, or unauthorized repairs or alterations. Should any defect in material or workmanship occur during the above time period in any product, as determined by HHI’s inspection of the product, HHI agrees, at its discretion, either to replace (not including installation) or repair the part or product free of charge. For customers in the U.S., delivery shall be made F.O.B. HHI’s place of business. For international customers, delivery shall be made FCA HHI place of business, United States of America (Incoterms 2010). No warranty claim will be honored without a valid proof of purchase. Customer must obtain a Return Goods Authorization as directed by HHI or its published repair center prior to shipping product for warranty evaluation. An explanation of the complaint must accompany the product. Product must be returned freight prepaid. Upon repair, the product will be covered for the remainder of the original warranty period. Replacement parts installed after the original warranty period will only be eligible for replacement (not including installation) for a period of one year from the installation date. If it is determined there is no defect, or that the defect resulted from causes not within the scope of HHI’s warranty, the customer will be responsible for the costs of returning the product. HHI DISCLAIMS ANY AND ALL OTHER WARRANTIES OF ANY KIND, EXPRESSED OR IMPLIED, AS TO THE PRODUCT’S MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. HHI WILL NOT BE LIABLE FOR DEATH, INJURIES TO PERSONS OR PROPERTY OR FOR INCIDENTAL, CONTINGENT, SPECIAL OR CONSEQUENTIAL DAMAGES, LOSS OR EXPENSE ARISING IN CONNECTION WITH THE USE OR MISUSE OF THE PRODUCTS, REGARDLESS OF WHETHER THE DAMAGE, LOSS OR EXPENSE RESULTS FROM ANY ACT OR FAILURE TO ACT BY HHI, WHETHER NEGLIGENT OR WILLFUL, OR FROM ANY OTHER CAUSE.
